Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork X Fusion
-
Groupset SX Eagle, Suntour SR -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
X-Fusion Sweep Boost RC 27.5", 15mm axle, tapered
Rear Shock
X-Fusion O2 Pro R, 210mm x 50mm
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1210 SX Eagle, 11-50 tooth, 12-speed
Crank
SR Suntour Zeron 1x, 175mm on L, 170mm on S/M
Bottom Bracket
BSA, 73mm
Chain
SRAM SX Eagle, 12-speed
Chain Guide
None
Pedals
Dartmoor Stream OEM
Wheels
Front Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel, Boost 148mm x 12mm
Rear Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel, Boost 148mm x 12mm
Rims
Dartmoor Cruiser 27.5", 32 hole, F/V
Tires
WTB Trail Boss G2 27.5" x 2.6", Comp
Brakes
Brakes
Tektro HD-M275, 180mm rotors
Brake Levers
Tektro HD-M275
Cockpit
Stem
Dartmoor Beetle, 33mm
Handlebar
Dartmoor Tornado Low 780mm, 31.8mm diameter
Grips
Dartmoor Maze Lite, without lock ring
Headset
Dartmoor Blink
Seat
Saddle
Dartmoor Arrow
Seatpost
X-Fusion Manic, Travel: 125mm on S, 150mm on M, 170mm on L
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.439 mm | 1.372 mm | 1.284 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm |
| Front Center | 706 mm | 726 mm | 736 mm |
| Rake | 32 mm | 32 mm | 14 mm |
| Trail | 123 mm | 123 mm | 143 mm |
| Stack | 597 mm | 597 mm | 597 mm |
| Reach | 415 mm | 435 mm | 465 mm |
| Top Tube Length | 590 mm | 610 mm | 640 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1136 mm | 1156 mm | 1166 mm |
| Bottom Bracket Drop | 23 mm | 23 mm | 23 mm |
| Standover Height | 785 mm | 785 mm | 785 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Bluebird EVO 27.5 belongs to the Dartmoor Bluebird model. 11 bikes variations carry this model name so far. You can easily view all of the Dartmoor Bluebird bikes models from 2020, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 15.9 kg (35.05 lbs), Dartmoor bike is much heavier than average. In other words, this model is 22.5% heavier than the average Trail bike.
Overview of components
Fork
Dartmoor Bluebird EVO 27.5 2020 bike is equipped with the X Fusion fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is X-Fusion O2 Pro R, with a travel distance of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Bluebird EVO 27.5 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Dartmoor Bluebird EVO 27.5 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Dartmoor Bluebird EVO 27.5 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
