Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Fork RST
-
Groupset X5, SRAM -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RST Storm RA
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X5
Front Derailleur
N/A
Shift Levers
SRAM SL-500, 9-speed
Cassette
Sunrace CSM980, 11-40 tooth, 9-speed
Crank
Dartmoor Rock v.2, 175mm length
Bottom Bracket
Dartmoor threaded, 73mm
Chain
SRAM PC-951
Chain Guide
N/A
Pedals
Dartmoor Stream OEM
Wheels
Front Hub
Front: Dartmoor Reel, 20mm x 110mm, Rear: Dartmoor Reel, 12mm x 142mm
Rear Hub
Front: Dartmoor Reel, 20mm x 110mm, Rear: Dartmoor Reel, 12mm x 142mm
Rims
Dartmoor Cruiser, 32 hole, F/V
Spokes
Sandvik T302 stainless steel
Tires
Innova IB-3004, 2.5”
Brakes
Brakes
SRAM Level with 180mm rotors
Brake Levers
SRAM Level
Cockpit
Stem
Dartmoor Fury v.3, 45mm length, 31.8mm clamp
Handlebar
Dartmoor Tornado, 780mm width, 31.8mm diameter
Grips
Dartmoor Race
Headset
Dartmoor Blink
Seat
Saddle
Dartmoor Trail v.2
Seatpost
Aluminum 6061, 350mm or 400mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.44 mm | 1.38 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm |
| Front Center | 728 mm | 753 mm | 783 mm |
| Rake | 43 mm | 43 mm | 52 mm |
| Trail | 118 mm | 118 mm | 108 mm |
| Stack | 617 mm | 617 mm | 617 mm |
| Reach | 402 mm | 427 mm | 447 mm |
| Top Tube Length | 592 mm | 617 mm | 647 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1148 mm | 1173 mm | 1203 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 802 mm | 802 mm | 802 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Hornet belongs to the Dartmoor Hornet model. There are 10 bikes that carry this model name. Take a sneak peek at all Dartmoor Hornet bikes models from 2018, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro bikes
According to our math, the average price for a trustworthy Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Hornet components
Fork
The fork installed on this bike is the RST model. The travel on this model is 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the Hornet model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hornet comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
