Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Fork SunTour Zeron
-
Groupset X4, X5 -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour Zeron35 LOR DS 27.5", Boost, 15mm axle, tapered
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X4, 9-speed
Front Derailleur
None
Shift Levers
SRAM X5, 9-speed
Cassette
SunRace CSM980, 11-40 tooth, 9-speed
Crank
SR Suntour Zeron 1x, 175mm on L/XL, 170mm on S/M
Bottom Bracket
BSA, 73mm
Chain
SunRace CNM94
Chain Guide
None
Pedals
Dartmoor Stream OEM
Wheels
Front Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel, Boost 148mm x 12mm
Rear Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel, Boost 148mm x 12mm
Rims
Dartmoor Cruiser 27.5"+, 32 hole, F/V
Tires
WTB Vigilante 27.5" x 2.8", Comp
Brakes
Brakes
Tektro HD-M275, 203mm rotor front, 180mm rotor rear
Brake Levers
Tektro HD-M275
Cockpit
Stem
Dartmoor Fury V.3, 45mm
Handlebar
Dartmoor Tornado Hi 780mm, 31.8mm diameter
Grips
Dartmoor Maze Lite, without lock ring
Headset
Dartmoor Blink
Seat
Saddle
Dartmoor Trail V.2
Seatpost
6061 alloy, 350mm on S/M, 400mm on L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.46 mm | 1.36 mm | 1.3 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm | 320 mm |
| Front Center | 735 mm | 760 mm | 790 mm | 810 mm |
| Rake | 37 mm | 37 mm | 37 mm | 37 mm |
| Trail | 132 mm | 132 mm | 132 mm | 132 mm |
| Stack | 622 mm | 622 mm | 622 mm | 622 mm |
| Reach | 402 mm | 427 mm | 457 mm | 477 mm |
| Top Tube Length | 593 mm | 617 mm | 647 mm | 669 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 455 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1155 mm | 1180 mm | 1210 mm | 1230 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 802 mm | 802 mm | 802 mm | 802 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Hornet is part of the Dartmoor Hornet model. 10 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Enduro bikes average weight
Enduro bikes weigh an average of 14.27 kg (31.46 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 15.56 kg (34.3 lbs), Dartmoor bike is a bit heavier than average. In short, the average Enduro bike weight is 9.04% lower than this one.
Overview of components
Fork
The SunTour Zeron is included from the factory. It has a travel distance of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Hornet 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Dartmoor Hornet has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Dartmoor Hornet bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
