Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Fork X Fusion
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
X-Fusion Sweep RC
Rear Shock
None
Drivetrain
Rear Derailleur
Shimano Deore M5100, 11-speed
Front Derailleur
None
Shift Levers
Shimano Deore M5100, 11-speed
Cassette
SunRace CSMS7, 11-speed, 11-51 tooth
Crank
Shimano Deore M5100, Length: 170mm (SM/MD), 175mm (LG/XL)
Chain
SunRace CN11A, 11-speed
Chain Guide
None
Wheels
Front Hub
Dartmoor Reel, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Dartmoor Reel, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Dartmoor Cruiser, 32 hole, tubeless ready
Spokes
Dartmoor wheelset
Tires
WTB Trail Boss, G2, Comp, 27.5" x 2.6"
Brakes
Brakes
Shimano MT410, 2-piston, 180mm rotors
Brake Levers
Shimano MT410
Cockpit
Stem
Dartmoor Beetle, 33mm length, 31.8mm bar clamp
Handlebar
Dartmoor Tornado Low, 780mm width, 31.8mm clamp diameter
Grips
Dartmoor Maze Lite, slip-on
Headset
Dartmoor Blink
Seat
Saddle
WTB Volt Medium, steel rails
Seatpost
6061 aluminum, Length: 350mm (SM/MD), 400mm (LG/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.43 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 729 mm | 749 mm | 769 mm | 789 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 618 mm | 618 mm | 618 mm | 618 mm |
| Reach | 411 mm | 431 mm | 451 mm | 471 mm |
| Top Tube Length | 594 mm | 614 mm | 634 mm | 654 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 435 mm | 455 mm | 475 mm | 495 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm | 115 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1146 mm | 1166 mm | 1186 mm | 1206 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 791 mm | 791 mm | 791 mm | 791 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Primal EVO 27.5 belongs to the Dartmoor Primal model. Dartmoor launched 16 bikes of this model so far. Take a sneak peek at all Dartmoor Primal bikes models from 2021, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 14.45 kg (31.86 lbs), Dartmoor bike is considerably heavier than average. In other words, this model is 11.33% heavier than the average Trail bike.
Primal EVO 27.5 components
Fork
The X Fusion is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Dartmoor Primal EVO 27.5 2021, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Primal EVO 27.5 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
