Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork X Fusion
-
Groupset SX Eagle, Suntour SR -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
X-Fusion Slide Boost RC 29", 15mm axle, tapered
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1210 SX Eagle, 11-50 tooth, 12-speed
Crank
SR Suntour Zeron 1x, 175mm on L/XL, 170mm on M
Bottom Bracket
BSA, 73mm
Chain
SRAM SX Eagle, 12-speed
Chain Guide
None
Pedals
Dartmoor Stream OEM
Wheels
Front Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel, Boost 148mm x 12mm
Rear Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel, Boost 148mm x 12mm
Rims
Dartmoor Tomcat 29", 32 hole, F/V
Tires
WTB Trail Boss G2 29" x 2.4", Comp
Brakes
Brakes
Tektro HD-M275, 180mm rotors
Brake Levers
Tektro HD-M275
Cockpit
Stem
Dartmoor Trail, 50mm
Handlebar
Dartmoor Tornado Low 780mm, 31.8mm diameter
Grips
Dartmoor Maze Lite, without lock ring
Headset
Dartmoor Blink
Seat
Saddle
Dartmoor Arrow
Seatpost
6061 alloy, 350mm on M, 400mm on L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.41 mm | 1.35 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm |
| Front Center | 744 mm | 764 mm | 784 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 111 mm |
| Stack | 640 mm | 640 mm | 640 mm |
| Reach | 434 mm | 454 mm | 474 mm |
| Top Tube Length | 624 mm | 644 mm | 664 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 475 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1173 mm | 1193 mm | 1213 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm |
| Standover Height | 794 mm | 794 mm | 794 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
Model Overview
Primal EVO 29 is a Dartmoor Primal model. There are 16 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Dartmoor Primal EVO 29 it’s weighing 14.3 kg (31.53 lbs). At this weight, is considerably heavier than average. In short, the average Trail bike weight is 10.17% lower than this one.
Primal EVO 29 components
Fork
This bike has the X Fusion fork installed. The fork’s travel is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Primal EVO 29 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Dartmoor Primal EVO 29 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, finding one for you shouldn’t be a problem.
