Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork RST
-
Groupset microSHIFT Advent, Deore -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RST Vibe Coil RA
Rear Shock
None
Drivetrain
Rear Derailleur
Microshift Advent M619M, 9-speed
Front Derailleur
None
Shift Levers
Microshift Advent Trail M9195-R, 9-speed
Cassette
Microshift Advent H093, 9-speed, 11-42 tooth
Crank
Shimano Deore M5100, Length: 170mm (SM/MD), 175mm (LG/XL)
Chain
SunRace CNM94, 9-speed
Chain Guide
None
Wheels
Front Hub
Dartmoor Reel, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rear Hub
Dartmoor Reel, 110x15mm Boost front, 148x12mm Boost rear with HG driver
Rims
Dartmoor Tomcat, 32 hole, tubeless ready
Spokes
Dartmoor wheelset
Tires
WTB Trail Boss, G2, Comp, 29" x 2.4"
Brakes
Brakes
Shimano MT200, 2-piston, 180mm rotors
Brake Levers
Shimano MT200
Cockpit
Stem
Dartmoor Trail v.2, 50mm length, 31.8mm bar clamp
Handlebar
Dartmoor Tornado Low, 780mm width, 31.8mm clamp diameter
Grips
Dartmoor Maze Lite, slip-on
Headset
Dartmoor Blink
Seat
Saddle
Dartmoor Fern
Seatpost
6061 aluminum, Length: 350mm (SM/MD), 400mm (LG/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.48 mm | 1.41 mm | 1.35 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm | 312 mm |
| Front Center | 724 mm | 744 mm | 764 mm | 784 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 111 mm | 111 mm |
| Stack | 637 mm | 637 mm | 637 mm | 637 mm |
| Reach | 411 mm | 431 mm | 451 mm | 471 mm |
| Top Tube Length | 601 mm | 621 mm | 641 mm | 661 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 435 mm | 455 mm | 475 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1150 mm | 1170 mm | 1190 mm | 1210 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 791 mm | 791 mm | 791 mm | 791 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Primal Intro 29 belongs to the Dartmoor Primal model. Dartmoor released 16 bikes variations of this model so far. Take a sneak peek at all Dartmoor Primal bikes models from 2021, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Trail bikes average weight
Trail bikes have an average weight of 12.98 kg (28.62 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Dartmoor Primal Intro 29 it’s weighing 14.95 kg (32.96 lbs). At this weight, is much heavier than average. In short, the average Trail bike weight is 15.18% lower than this one.
Overview of components
Fork
This bike has the RST fork installed. The fork’s travel is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Dartmoor Primal Intro 29 2021, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
