Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Fork Marzocchi Bomber Z2
-
Groupset SX Eagle, Suntour SR -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Marzocchi Bomber Z2 29, Boost, 15mm axle, tapered
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM PG-1230 NX Eagle, 11-50 tooth, 12-speed
Crank
SR Suntour Aion 1x, 7075 alloy, 175mm on L/XL, 170mm on M
Bottom Bracket
BSA, 73mm
Chain
SRAM NX Eagle, 12-speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel Pro, Boost 148mm x 12mm
Rear Hub
Front: Dartmoor Reel, Boost 110mm x 15mm, Rear: Dartmoor Reel Pro, Boost 148mm x 12mm
Rims
Dartmoor Tomcat 29", 32 hole, F/V
Tires
WTB Trail Boss G2 29" x 2.4", TCS Light, Fast Rolling
Brakes
Brakes
SRAM Level T, 180mm rotors
Brake Levers
SRAM Level T
Cockpit
Stem
Dartmoor Trail, 50mm
Handlebar
Dartmoor Nitro Low 800mm, 31.8mm diameter
Grips
Dartmoor Maze
Headset
Dartmoor Blink
Seat
Saddle
Dartmoor Arrow
Seatpost
X-Fusion Manic, Travel: 150mm on M, 170mm on L/XL
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.41 mm | 1.35 mm |
| Bottom Bracket Height | 312 mm | 312 mm | 312 mm |
| Front Center | 744 mm | 764 mm | 784 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 111 mm | 111 mm |
| Stack | 640 mm | 640 mm | 640 mm |
| Reach | 434 mm | 454 mm | 474 mm |
| Top Tube Length | 624 mm | 644 mm | 664 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 455 mm | 475 mm | 495 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1173 mm | 1193 mm | 1213 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm |
| Standover Height | 794 mm | 794 mm | 794 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Primal Pro 29 is part of the Dartmoor Primal model. 16 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.98 kg (28.62 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Dartmoor Primal Pro 29 it’s weighing 14 kg (30.86 lbs). At this weight, is a bit heavier than average. In conclusion, the average Trail bike weighs 7.86% less than Primal Pro 29.
Overview of components
Fork
The fork installed on this bike is the Marzocchi Bomber Z2 model. The travel on this model is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Primal Pro 29 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Primal Pro 29 comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Dartmoor Primal Pro 29 bike has 3 sizes, in the range of 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
Dartmoor Primal Pro 29 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
