Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 29" -
Travel Rear 140mm -
Suspension Full
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Carbon Construction
Drivetrain
Crank
Minimum Q-factor of 168mm
Bottom Bracket
73mm BSA Threaded
Cockpit
Headset
ZS44/28.6 upper and a ZS56/40 lower headset cup
Seat
Seatpost
Internal dropper routing with internal cable routing. 31.6”, Max Insertion Depth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.381 mm | 1.317 mm | 1.285 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 755 mm | 789 mm | 822 mm |
| Rake | 46 mm | 47 mm | 46 mm |
| Trail | 116 mm | 115 mm | 116 mm |
| Stack | 613 mm | 623 mm | 641 mm |
| Reach | 444 mm | 473 mm | 499 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1194 mm | 1228 mm | 1261 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Standover Height | 730 mm | 730 mm | 745 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
HIGHLANDEr 140 Frame is a Deviate Highlander model. There are 5 frames that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail frames average price
Our math shows that the average cost of a dependable Trail frame is 1736$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
Trail frames average weight
Trail frames have an average weight of 2.88 kg (6.35 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
considerably heavier than average, HIGHLANDEr 140 Frame has a weight of 3.2 kg (7.05 lbs). In conclusion, the average Trail frame weighs 11.11% less than HIGHLANDEr 140 Frame.
Overview of components
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Sizes
This frame is available in 3 sizes. They vary from 165 cm – 198 cm (5.41 ft – 6.5 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
