Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 29" -
Travel Rear 150mm -
Suspension Full
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Carbon Construction
Drivetrain
Crank
Minimum Q-factor of 168mm
Bottom Bracket
73mm BSA Threaded
Cockpit
Headset
ZS44/ZS56
Seat
Seatpost
Internal dropper routing with internal cable routing. 31.6”, Max Insertion Depth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.347 mm | 1.32 mm |
| Bottom Bracket Height | 341 mm | 341 mm | 341 mm |
| Front Center | 760 mm | 793 mm | 826 mm |
| Rake | 44 mm | 42 mm | 42 mm |
| Trail | 126 mm | 128 mm | 128 mm |
| Stack | 619 mm | 629 mm | 648 mm |
| Reach | 435 mm | 467 mm | 491 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Head Tube Angle | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 130 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1201 mm | 1235 mm | 1268 mm |
| Bottom Bracket Drop | 29 mm | 29 mm | 29 mm |
| Standover Height | 731 mm | 731 mm | 746 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
About this model
Highlander 150 Frame belongs to the Deviate Highlander model. Deviate launched 5 frames of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro frames
If you want an acceptable Enduro frame you should know that the average price is 1895$. However, even though the average price of an Enduro frame is lower, you might still be able to get a top-quality frame. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
Enduro frames average weight
If we make a quick analysis of the average weight of an Enduro frame, we get 3.44 kg (7.58 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
a bit lighter than average, Highlander 150 Frame has a weight of 3.2 kg (7.05 lbs). In conclusion, the average Enduro frame weighs 7.5% more than Highlander 150 Frame.
Overview of components
Rear Shock
Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Sizes
Highlander 150 Frame comes in 3 sizes, that range from 165 cm – 198 cm (5.41 ft – 6.5 ft). In short, you can easily find one that suits you.
Dropper post
The Deviate model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
