Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork Fox Performance Elite Float 36
-
Groupset GX, NX -
Suspension Full -
Motor Shimano 250W 70Nm mid-drive -
Battery Shimano STEPS E8020 504Wh Lithium-ion -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Optimum G04 150mm, Handcrafted in Canada / Fabriqué à la main au Canada
Suspension Fork
Fox Float 36 Performance Elite Evol 27.5 Boost 110 160mm
Rear Shock
Fox Float DPS Evol LV Performance Elite 185x55
Drivetrain
Rear Derailleur
SRAM GX 11s
Shift Levers
SRAM NX 11s
Cassette
SRAM PG1130-11s 11-42T
Crank
Shimano E8000
Chain
Shimano HG601-11s
Chain Guide
E13 Chain Guide for Steps
Wheels
Front Hub
SRAM MTH716 TA 15x110
Rear Hub
SRAM MTH746 TA 12x148 BOOST
Rims
V2 Comp Wide db Tubeless ready | 36mm inner
Spokes
Stainless 14G w/Nylok
Tires
Maxxis High Roller II 27.5x2.8" 3C Exo TL
Brakes
Brakes
SRAM Guide T
Cockpit
Stem
V2 Pro 35 | 50mm
Handlebar
V2 Pro 35 Riserbar15mm | 780mm
Grips
Devinci Performance w/lock-on
Headset
FSA Orbit 1.5 Zero Stack
Seat
Saddle
SDG Bel-Air 2
Seatpost
TranzX Dropper 31.6mm 1xLever SM:100 MD:125 LG:150 XL:170
Motor & Battery
Motor
Shimano STEPS E8000 250W
Battery
Shimano STEPS E8020 504Wh Lithium-ion
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.4 mm | 1.34 mm | 1.36 mm | 1.3 mm | 1.32 mm | 1.27 mm | 1.29 mm |
| Bottom Bracket Height | 359 mm | 352.5 mm | 359 mm | 352.5 mm | 359 mm | 352.5 mm | 359 mm | 352.5 mm |
| Stack | 583 mm | 587 mm | 592 mm | 596 mm | 601 mm | 605 mm | 615 mm | 619 mm |
| Reach | 423 mm | 418 mm | 443 mm | 438 mm | 463 mm | 458 mm | 483 mm | 478 mm |
| Top Tube Length | 574 mm | 576 mm | 597 mm | 599 mm | 620 mm | 622 mm | 645 mm | 647 mm |
| Seat Tube Angle | 75.6 ° | 75.1 ° | 75.6 ° | 75.1 ° | 75.5 ° | 75 ° | 75.4 ° | 74.9 ° |
| Seat Tube Length | 410 mm | 410 mm | 420 mm | 420 mm | 455 mm | 455 mm | 495 mm | 495 mm |
| Head Tube Angle | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 115 mm | 125 mm | 125 mm | 140 mm | 140 mm |
| Chainstay Length | 442 mm | 444 mm | 442 mm | 444 mm | 442 mm | 444 mm | 442 mm | 444 mm |
| Wheelbase | 1177 mm | 1179 mm | 1202 mm | 1203 mm | 1226 mm | 1227 mm | 1252 mm | 1253 mm |
| Bottom Bracket Drop | -4 mm | 3 mm | -4 mm | 3 mm | -4 mm | 3 mm | -4 mm | 3 mm |
| Standover Height | 719 mm | 712 mm | 736 mm | 729 mm | 764 mm | 758 mm | 797 mm | 789 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
DC NX/GX completes the Devinci E Dc model. 10 e-bikes variations carry this model name so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Devinci DC NX/GX 2019 is the cheapest e-bike model and costs 5669$. Devinci DC XT 2019 is the most expensive one and costs 6669$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro e-bikes
Our math shows that the average cost of a dependable Enduro e-bike is 4785$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Devinci DC NX/GX price was 5669$. If we compare this with the average Enduro e-bike cost we notice that the price is 18.47% higher.
DC NX/GX components
Fork
The fork installed on this bike is the Fox Performance Elite Float 36 model. The travel on this model is 160mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
From the factory, it comes with the Fox Float DPS Evol LV Performance Elite 185×55 rear shock model, which has a travel of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the DC NX/GX e-bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Devinci DC NX/GX is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Dropper post
Devinci DC NX/GX includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
