Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris, FSA -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
147cm - 160cm
SM
157cm - 171cm
MD
169cm - 180cm
LG
178cm - 187cm
XL
185cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum Optimum R03
Suspension Fork
Devinci Full Carbon
Drivetrain
Rear Derailleur
Shimano Claris R2000 | 8s
Front Derailleur
Shimano Claris R2000 |2s
Shift Levers
Shimano Claris ST-R2000 | 8s
Cassette
Shimano HG50 | 8s | 11-32T
Crank
FSA Tempo | 50/34T
Chain
KMC HG40 | 8s
Wheels
Front Hub
Formula Disc | Sealed bearing | QR 9x100mm
Rear Hub
Formula Disc sealed bearings | QR 10x135mm
Rims
V2 Comp db | 21mm inner
Spokes
Stainless 14G
Tires
Kenda Kwick Roller Sport | 700x32c
Brakes
Brakes
Tektro MD-C511 | Mechanical
Cockpit
Stem
V2 Pro | B:31.8mm | 6°
Handlebar
V2 Comp | B:31.8mm | R:75mm | D:120mm
Headset
FSA Orbit C40 | Integrated
Seat
Saddle
Devinci
Seatpost
Devinci | 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.404 mm | 1.46 mm | 1.497 mm | 1.544 mm | 1.579 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Stack | 528 mm | 559 mm | 584 mm | 613 mm | 638 mm |
| Reach | 376 mm | 383 mm | 390 mm | 397 mm | 404 mm |
| Top Tube Length | 527 mm | 543 mm | 562 mm | 583 mm | 598 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 440 mm | 490 mm | 530 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 140 mm | 165 mm | 195 mm | 220 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1020 mm | 1033 mm | 1044 mm | 1061 mm | 1071 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 676 mm | 707 mm | 740 mm | 774 mm | 809 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 157 cm | 169 cm | 178 cm | 185 cm |
| Rider Max Height | 160 cm | 171 cm | 180 cm | 187 cm | 193 cm |
About this model
Hatchet Claris 16S belongs to the Devinci Hatchet model. There are 65 bikes that carry this model name. You can easily view all of the Devinci Hatchet bikes models from 2023, here.
Model range prices
Devinci Hatchet Claris 16S 2023 is the most affordable bike of this model and has a price of 1301$. On the other hand, Devinci Hatchet Carbon GRX RX810 11S 2023, is the most expensive and costs 4799$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Devinci Hatchet Claris 16S price was 1301$. If we compare this with the average Gravel bike cost we notice that the price is 89.24% smaller.
Overview of components
Fork material
Hatchet Claris 16S has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Hatchet Claris 16S model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Devinci Hatchet Claris 16S is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Devinci Hatchet Claris 16S bike has 5 sizes, in the range of 147 cm – 193 cm (4.82 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
