Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Sektor
-
Groupset NX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon DMC-G 140mm
Suspension Fork
RockShox Sektor RL 27.5 Solo Air 150mm Boost 110x15
Rear Shock
Rock Shox Monarch RT3 Debonair 7.875x2.0
Drivetrain
Rear Derailleur
SRAM NX 11s
Shift Levers
SRAM NX 11s
Cassette
SRAM 11s 11-42T
Crank
SRAM NX 30T Boost 148
Bottom Bracket
SRAM BB92
Chain
Shimano 11s
Wheels
Front Hub
Formula TA 110mm
Rear Hub
Formula Boost148
Rims
V2 Comp db
Spokes
Stainless 14G w/Nylok
Tires
Maxxis HighRoller II 27.5x2.3" 3C Compound EXO protection
Brakes
Brakes
SRAM Level T
Disk Rotors
SRAM Centerline 180mm
Cockpit
Stem
V2 Pro 35mm
Handlebar
V2 Pro Riserbar 35mm 780mm
Grips
Devinci Performance w/lock-on
Headset
FSA Orbit 1.5 Zero Stack w/SL bearing
Seat
Saddle
SDG Bel-Air
Seatpost
FSA ajustable 125mm 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.43 mm | 1.37 mm | 1.39 mm | 1.33 mm | 1.35 mm | 1.3 mm | 1.32 mm |
| Bottom Bracket Height | 343 mm | 338 mm | 343 mm | 338 mm | 343 mm | 338 mm | 343 mm | 338 mm |
| Stack | 590 mm | 592 mm | 600 mm | 602 mm | 608 mm | 611 mm | 621 mm | 625 mm |
| Reach | 417 mm | 413 mm | 437 mm | 433 mm | 457 mm | 453 mm | 477 mm | 473 mm |
| Top Tube Length | 571 mm | 572 mm | 594 mm | 595 mm | 617 mm | 619 mm | 643 mm | 644 mm |
| Seat Tube Angle | 74.9 ° | 74.5 ° | 74.9 ° | 74.5 ° | 74.9 ° | 74.5 ° | 74.9 ° | 74.5 ° |
| Seat Tube Length | 410 mm | 410 mm | 435 mm | 435 mm | 470 mm | 470 mm | 500 mm | 500 mm |
| Head Tube Angle | 67.4 ° | 67 ° | 67.4 ° | 67 ° | 67.4 ° | 67 ° | 67.4 ° | 67 ° |
| Head Tube Length | 105 mm | 105 mm | 115 mm | 115 mm | 125 mm | 125 mm | 140 mm | 140 mm |
| Chainstay Length | 417 mm | 419 mm | 417 mm | 419 mm | 417 mm | 419 mm | 417 mm | 419 mm |
| Wheelbase | 1130 mm | 1131 mm | 1153 mm | 1155 mm | 1177 mm | 1179 mm | 1203 mm | 1204 mm |
| Bottom Bracket Drop | 12 mm | 17 mm | 12 mm | 17 mm | 12 mm | 17 mm | 12 mm | 17 mm |
| Standover Height | 707 mm | 702 mm | 718 mm | 713 mm | 731 mm | 726 mm | 745 mm | 740 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
Model Overview
Troy Carbon NX completes the Devinci Troy model. 66 bikes variations carry this model name so far. Take a sneak peek at all Devinci Troy bikes models from 2017, by clicking here.
Model range prices
Devinci Troy S 2017 is the cheapest bike model and costs 2299$. Devinci Troy Carbon X01 2017 is the most expensive one and costs 6729$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Devinci released this model in 2017, its price was 3539$. Doing a quick comparison, we notice that Troy Carbon NX price is 28.13% more expensive than the average cost of a Trail bike.
Troy Carbon NX components
Fork
The RockShox Sektor is included from the factory. It has a travel distance of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is Rock Shox Monarch RT3 Debonair 7.875×2.0, with a travel distance of 140mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When leaving the production line, the Troy Carbon NX model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
