diamant 365 2023
2023 E-bike
Estimate price |
2,558$
Weight | 17.2 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Altus -
Motor hub-drive -
Battery 250 Wh, integrated into the down tube, compatible with range extender -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 167cm
MD
164cm - 177cm
LG
174cm - 187cm
XL
185cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Gold Aluminum, internal cable routing, internal battery, rack & fender mounts, flat mount disc, kickstand mount, 144.5mm OLD hub motor spacing
Drivetrain
Rear Derailleur
Shimano Altus M2000, long cage
Shift Levers
Shimano Altus M2010, 9-speed
Cassette
Shimano HG200, 11-36 teeth, 9-speed
Crank
ProWheel Pro, aluminum, narrow-wide steel chainring (42 teeth), 170 mm crank arm length torque sensor, threaded, 122.5 mm axle length
Bottom Bracket
BSA, threaded
Chain
KMC E9S, 9-speed
Pedals
non-slip pedals with reflectors
Wheels
Front Hub
Formula DC-20, aluminum, 6-hole disc mount, 5 x 100 mm quick-release axle
Rear Hub
G2 hub motor
Rims
Bontrager Connection, hollow chamber rim, 32 holes, 20 mm inner width, Presta valve
Brakes
Brakes
Shimano hydraulic disc brake, MT200 brake lever, UR300 brake caliper
Cockpit
Stem
Bontrager Comp, 31 8mm, Blendr compatible, 7 degree, 70mm length
Handlebar
Aluminum low riser, 31.8mm, 25mm rise, 11 degree curvature, 660mm width
Seat
Saddle
Selle Royal Vivo Moderate Ergo
Seatpost
Aluminum Bontrager, 31.6mm, 12mm offset, 330mm length
Motor & Battery
Motor
G2 hub motor
Battery
250 Wh, integrated into the down tube, compatible with range extender
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.581 mm | 1.61 mm | 1.654 mm | 1.651 mm |
| Front Center | 63 mm | 64 mm | 65 mm | 66 mm |
| Rake | 7.6 mm | 7.3 mm | 6.9 mm | 6.6 mm |
| Trail | 115 mm | 112 mm | 108 mm | 105 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 408 mm | 463 mm | 507 mm | 558 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 154 cm | 164 cm | 174 cm | 185 cm |
| Rider Max Height | 167 cm | 177 cm | 187 cm | 197 cm |
About this model
365 belongs to the Diamant E 365 model. There are 2 e-bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Diamant 365 2023 is the most economical model, with a starting price of 2335$. Diamant 365 Deluxe 2023 on the other hand costs 2547$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter e-bikes average price
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When Diamant released this model in 2023, its price was 2335$. In conclusion, this e-bike price is 10.02% smaller than the price of the average Commuter e-bike.
Commuter e-bikes average weight
Commuter e-bikes weigh an average of 24.02 kg (52.95 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
With a weight of 17.2 kg (37.92 lbs), Diamant e-bike is much lighter than average. In conclusion, the average Commuter e-bike weighs 39.65% more than 365.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Wheels size
As for the wheels, Diamant 365 2023, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The 365 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
365 comes in 4 sizes, that range from 154 cm – 197 cm (5.05 ft – 6.46 ft). In conclusion, finding one for you shouldn’t be a problem.
