diamant Elan Deluxe 2021
2021 Urban
Estimate price |
1,162$
Weight | 15.5 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Fork Suntour NEX
-
Groupset Alivio, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 167cm
MD
164cm - 177cm
LG
174cm - 187cm
XL
185cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Smooth Aluminum, internal cable routing, post-mount disc, rack and mudguard mounts
Suspension Fork
SR Suntour NEX, coil spring, adjustable spring preload, 50 mm travel, 100 x 5 mm quick release axle
Drivetrain
Rear Derailleur
Shimano Alivio M3100, long cage
Shift Levers
Shimano Alivio M3100, 9-speed
Cassette
Shimano HG200, 11-36 teeth, 9-speed
Crank
Shimano MT210, 46/30, chain guard, 170 mm crank arm length
Chain
KMC E9S, 9-speed
Pedals
non-slip pedals with reflectors
Wheels
Front Hub
Shimano 3D37 hub dynamo
Rear Hub
Shimano TX505
Rims
Bontrager Connection hollow chamber rims
Brakes
Brakes
Shimano MT200 hydraulic disc brake
Cockpit
Stem
Bontrager Comp, 31 8mm, Blendr compatible, 7 degree, 80mm length
Handlebar
Aluminum low riser, 31.8mm, 25mm rise, 11 degree curvature, 660mm width
Seat
Saddle
Selle Royal Vivo Moderate Ergo
Seatpost
Bontrager, aluminum, 27.2mm, 12mm offset, 330mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.576 mm | 1.608 mm | 1.647 mm | 1.658 mm |
| Front Center | 63 mm | 63 mm | 64 mm | 66 mm |
| Rake | 8.4 mm | 8.1 mm | 7.7 mm | 7.4 mm |
| Trail | 116 mm | 112 mm | 109 mm | 105 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 500 mm | 500 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 154 cm | 164 cm | 174 cm | 185 cm |
| Rider Max Height | 167 cm | 177 cm | 187 cm | 197 cm |
About this model
Elan Deluxe is part of the Diamant Elan model. Diamant launched 3 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Diamant Elan Deluxe 2021 is the cheapest bike model and costs 1061$. Diamant Elan Grand Deluxe 2021 is the most expensive one and costs 1592$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2021 and its price was 1061$. If we compare this with the average Hybrid bike cost we notice that the price is 88.79% more expensive.
Hybrid bikes average weight
Hybrid bikes weigh an average of 13.85 kg (30.53 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Elan Deluxe weighs 15.5 kg (34.17 lbs) and is considerably heavier than the average. In short, the average Hybrid bike weight is 11.91% lower than this one.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
This bike has the Suntour NEX fork installed. The fork’s travel is 50mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The Elan Deluxe 2021 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Diamant Elan Deluxe has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Diamant Elan Deluxe bike has 4 sizes, in the range of 154 cm – 197 cm (5.05 ft – 6.46 ft). In short, it won’t be difficult to find the right one for you.
