Diamondback Andean 1 – Pre-built 2019
2019 Road
Estimate price |
3,999$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force, SRAM -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Andean Aero Core Triathlon Frameset, Unidirectional Carbon, 1" Headtube, Press-Fit 30 BB, Di2 Compatible Internal Cable Routing with integrated storage system
Suspension Fork
Andean Aero Triathlon Fork, Unidirectional Carbon,1" steer, Continuous Fiber Technology (CFT)
Drivetrain
Rear Derailleur
SRAM Force 1x
Shift Levers
SRAM 1150 R2C, 11 speed
Cassette
SRAM PG 1170, 11-Speed, 11-32
Crank
SRAM Force 1x : 52t
Bottom Bracket
SRAM PressFit 30
Chain
SRAM PC 1170 11-Speed
Wheels
Front Hub
HED Sonic Centerlock Disc, 24 hole
Rear Hub
HED 545 Centerlock Disc, 24 hole
Rims
HED Ardennes Plus LT
Spokes
HED Bladed Stainless Steel
Tires
Continental Grandprix Frorce 22c Front / Attack 24c Rear
Brakes
Brakes
TRP HY/RD Flat Mount cable pull hydraulic with 140mm TRP-25 Centerlock 2-piece rotors
Brake Levers
TRP RL 979 TT/Tri levers, carbon blade with cable and reach adjusters
Cockpit
Stem
DB Carbon TT w/ Full custom Internal cable routing system
Handlebar
Profile T2 Wing, 42cm Flat, 31.8mm Bar Bore with Diamondback J-Bend Alloy Clip-On
Grips
Diamondback EVA with PU coating
Headset
FSA orbit IS-2A integrated 1"
Seat
Saddle
ISM PS 1.1, Chromo Rails with Trihook nose
Seatpost
DB TT Aero Carbon w/ Ritchey Seat Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.28 mm | 1.3 mm | 1.31 mm | 1.32 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 581 mm | 592 mm | 615 mm | 637 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 68 mm | 59 mm | 59 mm | 59 mm |
| Stack | 486 mm | 514 mm | 539 mm | 564 mm |
| Reach | 381 mm | 396 mm | 411 mm | 426 mm |
| Top Tube Length | 467 mm | 487 mm | 507 mm | 526 mm |
| Seat Tube Angle | 80 ° | 80 ° | 80 ° | 80 ° |
| Seat Tube Length | 498 mm | 526 mm | 551 mm | 577 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 81 mm | 106 mm | 132 mm | 158 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 975 mm | 986 mm | 1009 mm | 1032 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Wheels | 700 | 700 | 700 | 700 |
Model Overview
Andean 1 – Pre-built belongs to the Diamondback Andean model. Diamondback released 15 bikes variations of this model so far. Take a sneak peek at all Diamondback Andean bikes models from 2019, by clicking here.
Model range prices
Diamondback Andean 1 – Pre-built 2019 is the cheapest bike model and costs 3999$. Diamondback Andean 3 – Pre-built 2019 is the most expensive one and costs 6999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Triathlon bikes
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, even if your budget is less than the average, you might still be able to get a top-quality Triathlon bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Diamondback released this model in 2019, its price was 3999$. Comparing this to the average Triathlon bike price, we see that the price is 4.45% smaller.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
Andean 1 – Pre-built has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the Andean 1 – Pre-built bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Diamondback Andean 1 – Pre-built has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
