Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTAP, RED eTAP -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Andean Aero Core Triathlon Frameset, Unidirectional Carbon, 1" Headtube, Press-Fit 30 BB, Di2 ready Internal Cable Routing, Integrated Storage System
Suspension Fork
Andean Aero Triathlon Fork, Unidirectional Carbon,1" steer, Continuous Fiber Technology (CFT)
Drivetrain
Rear Derailleur
SRAM Force eTap AXS, 12 speed
Front Derailleur
SRAM Force eTap AXS, Braze-on
Shift Levers
SRAM eTap Blip Button, w/ Clics Aero Buttons, 2x12 Speed
Cassette
SRAM XG-1270,10-26T
Crank
SRAM Force Carbon, 48/35T, w/ DUB Oversized Alloy Spindle
Bottom Bracket
SRAM PressFit 30 for DUB Spindle
Chain
SRAM Force, 12-speed
Wheels
Front Hub
Zipp 77D 6-Bolt Disc, 24 hole, 12mm Thru Axle
Rear Hub
Zipp 177D, 6-Bolt Disc, 24 hole, 12mm Thru Axle
Rims
Zipp 404 Firecrest Carbon Clincher Front / Zipp 808 Firecrest Carbon Clincher Rear
Spokes
Sapim CX-Ray, Straight Pull, Double Butted Stainless
Tires
Continental Grandprix 5000, 700x25c
Brakes
Brakes
SRAM S-900 Aero HDR Hydraulic Disc, 160/140mm CLX R Centerline 2-Piece Rotors
Brake Levers
SRAM S-900 Aero HDR Disc
Cockpit
Stem
DB Alloy TT, w/ Full Custom Internal Cable Routing System
Handlebar
Profile Design Aeria Ultimate Carbon, 42cm
Headset
FSA orbit IS-2A, Integrated 1", Sealed Cartridge Bearing
Seat
Saddle
ISM PN 3.1, 40-Serise Foam, Noseless Design, Chromoly Rails
Seatpost
Diamondback TT Aero Carbon, Ritchey WCS Seat Rail Clamp
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.28 mm | 1.3 mm | 1.31 mm | 1.32 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 581 mm | 592 mm | 615 mm | 637 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 68 mm | 59 mm | 59 mm | 59 mm |
| Stack | 486 mm | 514 mm | 539 mm | 564 mm |
| Reach | 381 mm | 396 mm | 411 mm | 426 mm |
| Top Tube Length | 467 mm | 487 mm | 507 mm | 526 mm |
| Seat Tube Angle | 80 ° | 80 ° | 80 ° | 80 ° |
| Seat Tube Length | 498 mm | 526 mm | 551 mm | 577 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 81 mm | 106 mm | 132 mm | 158 mm |
| Chainstay Length | 406 mm | 406 mm | 406 mm | 406 mm |
| Wheelbase | 975 mm | 986 mm | 1009 mm | 1032 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 739 mm | 770 mm | 791 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Andean 3 completes the Diamondback Andean model. Diamondback launched 15 bikes of this model so far. You can easily view all of the Diamondback Andean bikes models from 2020, here.
Model range prices
Diamondback Andean 1 2020 is the cheapest bike model and costs 4500$. Diamondback Andean 3 2020 is the most expensive one and costs 12000$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Triathlon bikes average price
If you want an acceptable Triathlon bike you should know that the average price is 4177$. However, this doesn’t mean that if you spend less money on a Triathlon bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 12000$. If we compare this with the average Triathlon bike cost we notice that the price is 187.29% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Andean 3 model has 700c carbon wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Andean 3 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Andean 3 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
