Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Diamondback Women's Specific Carbon Monocoque Endurance Road Frame, Internal Cable Routing, 142x12mm Carbon, Flat Mount Drop Outs, w/Taper Headtube, Di2 ready
Suspension Fork
Diamondback Road Performance, Full Monocoque Carbon "CFT", 12mm Thru-axle Drop Outs, Flat Mount Disc Tabs, 1.5" Tapered Steerer Tube
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700, 10 Speed
Front Derailleur
Shimano Tiagra FD-4700, 31.8mm Band Clamp
Shift Levers
Shimano Tiagra ST-4700, Dual Control 2x10 Speed
Cassette
Shimano HG500 Cassette, 10 Speed, 11-32T
Crank
Shimano Tiagra FC-4700 Compact, 50/34T
Bottom Bracket
Shimano Outboard Bearing
Chain
KMC X10, 10 Speed
Wheels
Front Hub
24h Alloy, Sealed Cartridge, 12mm Thru-axle
Rear Hub
24h Alloy, Sealed Cartridge, 142x12mm Thru-axle, Cassette
Rims
HED Flanders C2+ Disc, 24h
Spokes
14g Stainless Steel
Tires
Continental Ultra Sport II, Folding, 700x28c
Brakes
Brakes
TRP Spyre Flat Mount Disc, w/160mm Front / 160mm Rear Rotors
Brake Levers
Shimano Tiagra ST-4700
Cockpit
Stem
HED Tour Stem, +/-7° Rise, 31.8mm Bar Bore
Handlebar
HED Tour Flat Top Drop Bar, 31.8 Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA No.42, Sealed Cartridge
Seat
Saddle
Prologo Kappa Evo PAS, T2.0 Chromoly Rail
Seatpost
HED Tour, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.49 mm | 1.53 mm | 1.58 mm | 1.61 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 266 mm |
| Front Center | 583 mm | 581 mm | 583 mm | 594 mm | 598 mm |
| Rake | 47.5 mm | 47.5 mm | 47.5 mm | 47.5 mm | 47.5 mm |
| Trail | 65 mm | 66 mm | 60 mm | 60 mm | 58 mm |
| Stack | 518 mm | 545 mm | 568 mm | 592 mm | 610 mm |
| Reach | 369 mm | 367 mm | 371 mm | 374 mm | 378 mm |
| Top Tube Length | 503 mm | 513 mm | 528 mm | 543 mm | 558 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 440 mm | 460 mm | 480 mm | 500 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 105 mm | 130 mm | 150 mm | 175 mm | 195 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 990 mm | 988 mm | 990 mm | 1001 mm | 1006 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 701 mm | 723 mm | 745 mm | 768 mm | 791 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Arden 4 Carbon is part of the Diamondback Arden model. Diamondback launched 12 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Diamondback Arden 1 2020 is the most affordable bike of this model and has a price of 700$. On the other hand, Diamondback Arden 5 Carbon 2020, is the most expensive and costs 2500$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2020 for 1900$. Comparing the average cost of an Endurance bike to this one, you will see that Arden 4 Carbon price is 23.47% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
Arden 4 Carbon has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
When it comes to wheels, the Arden 4 Carbon bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Arden 4 Carbon comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
