Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Diamondback Women's Specific Carbon Monocoque Endurance Road Frame, Internal Cable Routing, 142x12mm Carbon, Flat Mount Drop Outs, w/Taper Headtube, Di2 ready
Suspension Fork
Diamondback Road Performance, Full Monocoque Carbon "CFT", 12mm Thru-axle Drop Outs, Flat Mount Disc Tabs, 1.5" Tapered Steerer Tube
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000, 11 Speed, GS
Front Derailleur
Shimano 105 FD-R7000, 31.8mm Band Clamp
Shift Levers
Shimano 105 ST-R7025, Dual Control 2x11 Speed, Short Reach Lever
Cassette
Shimano 105 CS-R7000 Cassette, 11 Speed, 11-32T
Crank
Shimano 105 FC-7000 Compact, 50/34T
Bottom Bracket
Shimano Outboard Bearing
Chain
KMC X11EL, 11 Speed
Wheels
Front Hub
24h Alloy, Sealed Cartridge, Center Lock, 12mm Thru-axle
Rear Hub
24h Alloy, Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette
Rims
HED Flanders C2+ Disc, 24h
Spokes
2.0/1.8/2.0 Butted Stainless Steel
Tires
Continental Grand Sport Race, Folding, 700x28c
Brakes
Brakes
Shimano 105 ST-R7070, w/160mm Front / 160mm Rear Rotors
Brake Levers
Shimano 105 ST-R7025, Short Reach Levers
Cockpit
Stem
HED Tour Stem, +/-7° Rise, 31.8mm Bar Bore
Handlebar
HED Tour Flat Top Drop Bar, 31.8 Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA No.42, Sealed Cartridge
Seat
Saddle
Prologo Kappa DEA2, w/Chromoly Rails
Seatpost
HED Pro Tour Carbon, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50cm | 52cm | 54cm | 56cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.49 mm | 1.53 mm | 1.58 mm | 1.61 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm | 266 mm |
| Front Center | 583 mm | 581 mm | 583 mm | 594 mm | 598 mm |
| Rake | 47.5 mm | 47.5 mm | 47.5 mm | 47.5 mm | 47.5 mm |
| Trail | 65 mm | 66 mm | 60 mm | 60 mm | 58 mm |
| Stack | 518 mm | 545 mm | 568 mm | 592 mm | 610 mm |
| Reach | 369 mm | 367 mm | 371 mm | 374 mm | 378 mm |
| Top Tube Length | 503 mm | 513 mm | 528 mm | 543 mm | 558 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 440 mm | 460 mm | 480 mm | 500 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 105 mm | 130 mm | 150 mm | 175 mm | 195 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 990 mm | 988 mm | 990 mm | 1001 mm | 1006 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 701 mm | 723 mm | 745 mm | 768 mm | 791 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Arden 5 Carbon belongs to the Diamondback Arden model. 12 bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Diamondback Arden 1 2019 is the most economical model, with a starting price of 699$. Diamondback Arden 5 Carbon 2019 on the other hand costs 2499$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Diamondback released this model in 2019, its price was 2499$. In conclusion, this bike price is 6.52% more expensive than the price of the average Endurance bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Arden 5 Carbon components
Fork material
Arden 5 Carbon has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the Arden 5 Carbon model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Arden 5 Carbon has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
