Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 100mm -
Fork SunTour XCM
-
Groupset X5, X4 -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Atroz 6061 T-6 Aluminum 27.5 Trail w/ 4" travel, Optimized Single Pivot, Tapered Steerer, Machine Formed Top Tube, Butted / Formed Down Tube, Sealed Cartridge Bearing Pivot, Aggressive Geometry, replaceable hanger
Suspension Fork
SR Suntour XCM 120mm Travel, 30mm Stanchions, w/ Preload Adjust
Rear Shock
SR Suntour Raidon-R, Air Shock w/ Rebound Adjust, 184x44mm
Drivetrain
Rear Derailleur
SRAM X5, 9 Speed
Front Derailleur
Full ISCG-05 Chain Guide w/ Roller
Shift Levers
SRAM X4 9 Speed
Cassette
SRAM PG950, 9 Speed, 11-34T
Crank
Alloy Arm w/ 32T Alloy Single Ring
Bottom Bracket
Sealed Cartridge
Chain
KMC Z99, 9 Speed
Pedals
DB4L Alloy Platform
Wheels
Front Hub
32h SL-7 Alloy w/ CNC Disc Mount
Rear Hub
32h SL-7 Alloy Cassette w/ CNC Disc mount
Rims
32h Diamondback SL-7 Doublewall
Spokes
14g Stainless Steel
Tires
Kenda Nevegal Lite, 27.5x2.35"
Brakes
Brakes
Tektro Auriga Hydraulic Disc w/ 180mm Front /160mm Rear Rotors
Brake Levers
Tektro 2 Finger Hydraulic w/ Reach Adjust
Cockpit
Stem
Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore
Handlebar
Diamondback "Pro Bar", 750mm Wide, 31.8 Bar Bore
Grips
DB4L 135mm Kraton
Headset
Ahead 1 1/8" Zero Stack
Seat
Saddle
DB Sync'r Saddle
Seatpost
Alloy Micro Adjust 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm |
| Front Center | 660 mm | 695 mm | 726 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 107 mm | 107 mm | 107 mm |
| Stack | 556 mm | 556 mm | 565 mm |
| Reach | 370 mm | 405 mm | 432 mm |
| Top Tube Length | 547 mm | 582 mm | 612 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1092 mm | 1127 mm | 1158 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm |
| Standover Height | 752 mm | 768 mm | 772 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Atroz 2 is a Diamondback Atroz model. Diamondback launched 22 bikes of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2017 for 999$. If we compare this with the average Crosscountry bike cost we notice that the price is 90.69% smaller.
Atroz 2 components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the SR Suntour Raidon-R model, with a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Diamondback Atroz 2 2017, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Atroz 2 comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
