Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 100mm -
Fork SunTour XCM
-
Groupset X5, X4 -
Suspension Full -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Atroz 6061 T-6 Aluminum 27.5 Trail w/ 4" travel, Optimized Single Pivot, Tapered Steerer, Machine Formed Top Tube, Butted / Formed Down Tube, Sealed Cartridge Bearing Pivot, Aggressive Geometry, replaceable hanger
Suspension Fork
SR Suntour XCM 120mm Travel, 30mm Stanchions, w/ Preload Adjust
Rear Shock
SR Suntour Raidon-R, Air Shock w/ Rebound Adjust, 184x44mm
Drivetrain
Rear Derailleur
SRAM X5, 9 Speed
Front Derailleur
Full ISCG-05 Chain Guide w/ Roller
Shift Levers
SRAM X4 9 Speed
Cassette
SRAM PG950, 9 Speed, 11-34T
Crank
Alloy Arm w/ 32T Alloy Single Ring
Bottom Bracket
Sealed Cartridge
Chain
KMC Z99, 9 Speed
Pedals
DB4L Alloy Platform
Wheels
Front Hub
32h SL-7 Alloy w/ CNC Disc Mount
Rear Hub
32h SL-7 Alloy Cassette w/ CNC Disc mount
Rims
32h Diamondback SL-7 Doublewall
Spokes
14g Stainless Steel
Tires
Kenda Nevegal Lite, 27.5x2.35"
Brakes
Brakes
Tektro Auriga Hydraulic Disc w/ 180mm Front /160mm Rear Rotors
Brake Levers
Tektro 2 Finger Hydraulic w/ Reach Adjust
Cockpit
Stem
Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore
Handlebar
Diamondback "Pro Bar", 750mm Wide, 31.8 Bar Bore
Grips
DB4L 135mm Kraton
Headset
Ahead 1 1/8" Zero Stack
Seat
Saddle
DB Sync'r Saddle
Seatpost
Alloy Micro Adjust 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Top Tube Length | 547 mm | 582 mm | 612 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1092 mm | 1127 mm | 1158 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm |
| Standover Height | 752 mm | 768 mm | 772 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Atroz is a Diamondback Atroz model. Diamondback launched 22 bikes of this model so far. Take a sneak peek at all Diamondback Atroz bikes models from 2017, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The SunTour XCM is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Diamondback Atroz bike has the SR Suntour Raidon-R model installed, and has a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Atroz bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Atroz is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
