Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 100mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Atroz 6061 T-6 Aluminum 27.5 Trail w/ 4" travel, Optimized Single Pivot, Tapered Steerer, Machine Formed Top Tube, Butted / Formed Down Tube, Sealed Cartridge Bearing Pivot, Seat Tube Routed for Internal Dropper Post, Aggressive Geometry, 142x12mm Rear Axle w/ Replaceable Hanger
Suspension Fork
RockShox Recon RL, Solo Air, 130mm Travel, 32mm Stanchions, 15mm Thru-Axle, 1.5" Tapered Steerer Tube, w/ Rebound and Lock Out Adjust
Rear Shock
RockShox Monarch R, Air Shock w/ Rebound Adjust, 184x44mm
Drivetrain
Rear Derailleur
SRAM SX EAGLE, 12 Speed
Shift Levers
SRAM SX 12 Speed X-Actuation Trigger
Cassette
SRAM PG1210, 12 Speed, 11-50T
Crank
Race Face Æffect Cinch w/ Steel 30T "Narrow Wide"
Bottom Bracket
Race Face Outboard Bearing
Chain
KMC X12, 12 Speed
Pedals
DB4L Aluminum Platform
Wheels
Front Hub
Formula Hub, 32h Aluminum Boost 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
Formula Hub, 32h Aluminum 142x12mm Thru-axle, 4 Sealed Cartridge Bearings, Cassette, w/ CNC Disc Mount
Rims
32H, DDM-5, 27.5 Doublewall, Not Taped
Spokes
14g Stainless Steel
Tires
VEE Rubber, Mission, 27.5x2.3, Non Tubeless Tire
Brakes
Brakes
Shimano MT200 Hydraulic Disc, w/ 180mm Front and 160mm Rear Rotors
Brake Levers
Shimano MT200 Hydraulic
Cockpit
Stem
Race Face Chester, 40mm Reach, 35 Bar Bore
Handlebar
Race Face Chester, 780mm Wide, 35 Bar Bore
Grips
New DB "Flanged" Lock-on, 135mm Silcone
Headset
FSA NO.57, Sealed Cartridge for Tapered Headtube
Seat
Saddle
DB Sync'r Saddle
Seatpost
Aluminum Micro Adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm |
| Front Center | 660 mm | 695 mm | 726 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 107 mm | 107 mm | 107 mm |
| Stack | 556 mm | 556 mm | 565 mm |
| Reach | 370 mm | 405 mm | 432 mm |
| Top Tube Length | 547 mm | 582 mm | 612 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1092 mm | 1127 mm | 1158 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm |
| Standover Height | 749 mm | 765 mm | 798 mm |
| Front Travel | 130 mm | 130 mm | 130 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Atroz 3 belongs to the Diamondback Atroz model. Diamondback released 22 bikes variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Diamondback Atroz 1 2023 is the cheapest bike model and costs 1075$. Diamondback Atroz 3 2023 is the most expensive one and costs 1950$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2023 and its price was 1950$. Comparing this to the average Crosscountry bike price, we see that the price is 2.36% higher.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Atroz 3 components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Diamondback Atroz 3 bike has the RockShox Monarch R model installed, and has a travel of 100mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Atroz 3 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Atroz 3 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Diamondback Atroz 3 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
