Diamondback Calico Sport 2017
2017 Urban
Estimate price |
599$
Weight | 14.51 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork SunTour
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Calico 6061-T6 Butted Aluminum Dual Sport Frame w/ Formed Top and Down Tube, Forged Drop Outs, w/ Integrated Chainstay Disc Mount
Suspension Fork
SR Suntour NVX HLO 700c, 75mm Travel, 28mm Stanchions, Alloy Lower, Alloy Crown, Coil Spring w/ Preload Adjust w/Lock out
Drivetrain
Rear Derailleur
Shimano Acera 8 Speed
Front Derailleur
Shimano Acera M310, Top Swing, Dual Pull, 31.8 Clamp Diameter
Shift Levers
Shimano SL-M310 Rapidfire, 3x8 Speed
Cassette
Shimano HG-31, 8 Speed, 11-32T
Crank
Shimano FC-M311, 48X38X28T
Bottom Bracket
Sealed Cartridge
Chain
KMC-Z82, 8 Speed
Pedals
Wellgo Alloy forged, CNC MTB
Wheels
Front Hub
32h SL-7 Alloy w/ CNC Disc Mount
Rear Hub
32h SL-7 Alloy Cassette w/ CNC Disc mount
Rims
32h Diamondback SL-7 Doublewall
Spokes
14g Stainless Steel
Tires
Kenda Bitumen, 700x45c
Brakes
Brakes
Tektro Aries Disc w/ 160mm Rotors
Brake Levers
Tektro 3 finger Alloy Linear w/ Reach Adjust
Cockpit
Stem
DB 3D Forged, 7° Rise, 31.8 Bar Bore
Handlebar
DB Laser Series, Low rise, 640mm Wide, 31.8mm Bar Bore
Grips
Diamondback Dual Density Comfort Grip
Headset
Ahead 1 1/8"
Seat
Saddle
DB Dual Sport Series
Seatpost
DB Laser Micro Adjust 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.65 mm | 1.6 mm | 1.59 mm |
| Front Center | 593 mm | 592 mm | 611 mm | 632 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm |
| Trail | 76 mm | 73 mm | 74 mm | 72 mm |
| Stack | 598 mm | 610 mm | 619 mm | 637 mm |
| Reach | 369 mm | 370 mm | 387 mm | 401 mm |
| Top Tube Length | 541 mm | 551 mm | 576 mm | 596 mm |
| Seat Tube Angle | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 350 mm | 400 mm | 450 mm | 500 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1043 mm | 1042 mm | 1061 mm | 1082 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 716 mm | 757 mm | 793 mm | 835 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Calico Sport is part of the Diamondback Calico model. 4 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
The most economical model, the Diamondback Calico 2017 has a starting price of 499$. Diamondback Calico Sport 2017 on the other hand is the most expensive at 599$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hybrid bikes
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2017 for 599$. If we compare this with the average Hybrid bike cost we notice that the price is 6.58% higher.
Hybrid bikes average weight
Hybrid bikes weigh an average of 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Diamondback Calico Sport it’s weighing 14.51 kg (31.99 lbs). At this weight, is slightly heavier than average. In other words, this model is 4.77% heavier than the average Hybrid bike.
Overview of components
Fork
Diamondback Calico Sport 2017 bike is equipped with the SunTour fork, and has 75mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Calico Sport model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Calico Sport comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, finding one for you shouldn’t be a problem.
