Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
El Oso Butted Heat Treat Steel 1-1/8"Headtube, 150mm Rear OLD, Fits up to 26x5" tire
Suspension Fork
DB El Oso Custom Rigid Steel Fork, 1-1/8", 135mm QR Dropouts
Drivetrain
Rear Derailleur
Shimano Alivio M4000
Front Derailleur
Shimano Alivio M410 E-Type
Shift Levers
Shimano Alivio M4000 9spd
Cassette
Shimano HG300 9spd (12-36t)
Crank
Shimano Acera M3000, 40/30/22T
Bottom Bracket
Sealed Cartridge
Chain
KMC X9 EPT Anti-Rust
Pedals
DB Alloy w/ molded traction pins
Wheels
Front Hub
Alloy 32h Disc, 3/8" Nutted 135mm
Rear Hub
Alloy 32h Dsic, Cassette, 3/8" Nutted 150mm
Rims
DB75mm Wide w/28mm cutout, singlewall 32h
Spokes
14g Stainless Steel
Tires
Chaoyang Cruiser 26"x4.0"
Brakes
Brakes
Tektro Mira Mechanical Disc, 160mm/160mm Rotor
Brake Levers
Tektro RAL84A
Cockpit
Stem
DB 3D Forged, +/-7° Rise 31.8
Handlebar
DB Pro Bar740mm width, 15mm rise, 31.8mm barbore
Grips
DB High Density Foam Grip
Headset
Threadless 1-1/8" Aheadset
Seat
Saddle
DB Race M-series saddle w/ cromo rails
Seatpost
DB Alloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Top Tube Length | 580 mm | 609 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Standover Height | 787 mm | 804 mm | 820 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
El Oso de Acero is part of the Diamondback El Oso model. Diamondback released 23 bikes variations of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fatbike bikes
If you want an acceptable Fatbike bike you should know that the average price is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The El Oso de Acero 2017 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
El Oso de Acero comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
