Diamondback El Oso Dos 2017
2017 Mountain
Estimate price |
1,500$
Weight | 16.15 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Deore, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
El Oso 6061-T6 double-butted aluminum, formed top/down tube, 1.5" tapered machined head tube
Suspension Fork
DB El Oso Custom Rigid air-formed alloy fork, 1.5 taper steerer, 150mm x 15mm thru-axle
Drivetrain
Rear Derailleur
Shimano Deore M6000 Shadow Plus, 10 Speed
Front Derailleur
Shimano Deore M6020, Side Swing, Front Pull, Direct Mount
Shift Levers
Shimano Deore M6000, 10 Speed
Cassette
Shimano HG500, 10 Speed, 11-42T
Crank
FSA Comet Mega Exo, 36/24T
Bottom Bracket
FSA Mega Exo
Chain
KMC X10, 10 Speed, EPT anti-rust
Pedals
DB4L alloy platform with replaceable pins
Wheels
Front Hub
32h alloy, sealed cartridge bearing, 150mmx15mm Thru-axle
Rear Hub
32h alloy, sealed cartridge bearing, 197mmx12mm Thru-axle
Rims
Diamondback 95mm wide with 50mm cutouts, 32h alloy singlewall
Tires
Kenda Juggernaut 26 x 4.5
Brakes
Brakes
TRP Spyke Dual Piston Mechanical Disc, with 160mm front and rear rotors Mechanical Disc Brake
Brake Levers
TRP ML800 Spyke
Cockpit
Stem
DB 3D forged, 7-degree rise, 31.8 bar bore
Handlebar
Diamondback, 740mm wide, 15mm rise, 31.8 bar bore
Headset
FSA No.57, sealed cartridge
Seat
Saddle
DB Race M-series
Seatpost
DB Alloy Micro Adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.471 mm | 1.403 mm | 1.338 mm |
| Bottom Bracket Height | 319 mm | 319 mm | 319 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Stack | 600 mm | 609 mm | 609 mm |
| Reach | 408 mm | 434 mm | 455 mm |
| Top Tube Length | 580 mm | 609 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 457 mm | 500 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1125 mm | 1155 mm | 1176 mm |
| Bottom Bracket Drop | 24 mm | 24 mm | 24 mm |
| Standover Height | 787 mm | 804 mm | 820 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
El Oso Dos is part of the Diamondback El Oso model. 23 bikes variations carry this model name so far. You can easily view all of the Diamondback El Oso bikes models from 2017, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Fatbike bikes
If you want an acceptable Fatbike bike you should know that the average price is 1743$. However, you could also get a good Fatbike bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Diamondback released this model in 2017, its price was 1500$. Comparing this to the average Fatbike bike price, we see that the price is 16.2% smaller.
Average weight for Fatbike bikes
If we make a quick analysis of the average weight of a Fatbike bike, we get 13.2 kg (29.1 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
much heavier than average, El Oso Dos has a weight of 16.15 kg (35.6 lbs). In short, the average Fatbike bike weight is 22.35% lower than this one.
El Oso Dos components
Fork material
El Oso Dos has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The El Oso Dos 2017 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
When you want to stop the bike in time, the brakes are vital. The El Oso Dos has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
El Oso Dos comes in 3 sizes, that range from 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, you can easily find one that suits you.
