Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Deore, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
El Oso 6061-T6 Double Butted Aluminum, Formed Top / Down Tube, 1.5" Tapered Machined Headtube, 197mm Thru Axle, Fits up to 26x5" Tire
Suspension Fork
DB El Oso Custom Rigid Air Formed Alloy Fork, 1.5 Taper Steerer, 150mmx15mm Thru-axle
Drivetrain
Rear Derailleur
Shimano Deore M6000 Shadow Plus, 10 Speed, GS
Front Derailleur
Shimano Deore M617 Side Swing, Front Pull, Direct Mount
Shift Levers
Shimano Deore M6000, 10 Speed
Cassette
Shimano HG500, 10 Speed, 11-42T
Crank
FSA Comet Mega Exo, 36/24T
Bottom Bracket
FSA Mega Exo
Chain
KMC X10, 10 Speed, EPT Anti-Rust
Pedals
DB4L Alloy Platform w/Replaceable Pins
Wheels
Front Hub
32h Alloy, Sealed Cartridge Bearing, 150mmx15mm Thru-axle
Rear Hub
32h Alloy, Sealed Cartridge Bearing, 197mmx12mm Thru-axle, Cassette
Rims
Diamondback 90mm Wide w/Cutouts, 32h Alloy Single wall
Spokes
14g Stainless Steel
Tires
Kenda Juggernaut 26x4.5", 60tpi, Folding
Brakes
Brakes
TRP Slate X2, w/160mm Front /160mm Rear Rotors
Brake Levers
TRP Slate X2
Cockpit
Stem
DB 3D Forged, 7° Rise, 31.8 Bar Bore
Handlebar
Diamondback, 740mm Wide, 15mm Rise, 31.8 Bar Bore
Grips
DB High Density Foam Grip
Headset
FSA No.57, Sealed Cartridge
Seat
Saddle
WTB Volt Comp
Seatpost
DB Alloy Micro Adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | SM | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.46 mm | 1.33 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm |
| Front Center | 702 mm | 672 mm | 722 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 87 mm | 87 mm | 87 mm |
| Stack | 614 mm | 605 mm | 614 mm |
| Reach | 439 mm | 413 mm | 460 mm |
| Top Tube Length | 462 mm | 585 mm | 635 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 609 mm | 400 mm | 500 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 120 mm | 110 mm | 120 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm |
| Wheelbase | 1160 mm | 1130 mm | 1181 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 809 mm | 792 mm | 825 mm |
| Wheels | 26" | 26" | 26" |
About this model
El Oso Dos is a Diamondback El Oso model. 23 bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Diamondback El Oso Nino 20 2019 has a starting price of 449$. Diamondback El Oso Tres 2019 on the other hand is the most expensive at 2199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Fatbike bikes average price
According to our math, the average price for a trustworthy Fatbike bike is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1499$. Doing a quick comparison, we notice that El Oso Dos price is 16.28% smaller than the average cost of a Fatbike bike.
Overview of components
Fork material
El Oso Dos has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on El Oso Dos are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
