Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Groupset Acera, Alivio -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
El Oso Butted Heat Treated Steel, 1-1/8" Headtube, 170mm Rear OLD, w/Laser Cut Disc Drop Outs, Fits up to 26x5" tire
Suspension Fork
DB El Oso Custom Rigid Steel Fork, 1-1/8" Steerer Tube, 135mm QR Disc Dropouts
Drivetrain
Rear Derailleur
Shimano Acera M3000, Shadow, 9 Speed, SGS
Front Derailleur
Shimano Alivio M4020-D, Side Swing, Front Pull, Direct Mount
Shift Levers
Shimano Acera M3000, 2x9 Speed Rapidfire
Cassette
Shimano HG200, 9 Speed, 11-36T
Crank
SR Suntour XCM, 36/22T
Bottom Bracket
Sealed Cartridge
Chain
KMC X9 EPT Anti-Rust
Pedals
DB4L Alloy Platform
Wheels
Front Hub
32h Alloy, 3/8" Nutted
Rear Hub
32h Alloy, 3/8" Nutted, Cassette
Rims
Diamondback 73mm Wide w/28mm Cutouts, 32h Alloy Singlewall
Spokes
14g Stainless Steel
Tires
Chaoyang Cruiser 26x4.0"
Brakes
Brakes
Tektro Aires Mechanical Disc, w/180mm Front / 160mm Rear Rotors
Brake Levers
Tektro 2 Finger Alloy
Cockpit
Stem
DB 3D Forged, 7° Rise, 31.8 Bar Bore
Handlebar
Diamondback, 740mm Wide, 15mm Rise, 31.8 Bar Bore
Grips
DB High Density Foam Grip
Headset
FSA Orbit, No.8B
Seat
Saddle
DB Race M-series Saddle
Seatpost
DB Alloy Micro Adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.457 mm | 1.393 mm | 1.327 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm |
| Front Center | 677 mm | 706 mm | 727 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 81 mm | 81 mm | 81 mm |
| Stack | 596 mm | 606 mm | 605 mm |
| Reach | 409 mm | 435 mm | 456 mm |
| Top Tube Length | 580 mm | 609 mm | 630 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 120 mm | 120 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1130 mm | 1160 mm | 1181 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 787 mm | 804 mm | 820 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
el Oso Uno completes the Diamondback El Oso model. Diamondback launched 23 bikes of this model so far. Take a sneak peek at all Diamondback El Oso bikes models from 2020, by clicking here.
Model range prices
Diamondback El Oso Niño 20″ 2020 is the most economical model, with a starting price of 575$. Diamondback el Oso Tres 2020 on the other hand costs 2200$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Fatbike bikes average price
According to our math, the average price for a trustworthy Fatbike bike is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2020 and its price was 850$. Doing a quick comparison, we notice that el Oso Uno price is 105.06% smaller than the average cost of a Fatbike bike.
Overview of components
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When it comes to wheels, the el Oso Uno bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The el Oso Uno has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, you won’t have a problem finding one that suits you.
