Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Women's Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Alloy, Formed Top Tube, 1 1/8" Headtube, Replaceable Hanger
Suspension Fork
DB Steel Gravel Disc, 1-1/8" Steerer Tube, w/Fender and Low Rider Mounts
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000, 8 Speed, GS
Front Derailleur
Shimano Claris FD-R2000, 31.8mm Band Clamp
Shift Levers
Shimano Claris ST-R2000 STI, 2x8 Speed
Cassette
Shimano HG50 Cassette, 8 Speed, 11-32T
Crank
Alloy, Compact Cross, 46/34T
Bottom Bracket
Steel Cartridge
Chain
KMC Z8, 8 Speed
Pedals
DB Platform
Wheels
Front Hub
28h Alloy Quick Release
Rear Hub
28h Alloy Quick Release, Cassette
Rims
Diamondback Equation CX, 28h, Doublewall
Spokes
14g Stainless Steel
Tires
Diamondback Interval Wire Bead, 700x38c, Reflective Sidewall, 60TPI
Brakes
Brakes
Tektro Mira Post Mount Mechanical Disc, w/160mm Front / 140mm Rear Rotors
Brake Levers
Shimano Claris ST-2400
Cockpit
Stem
DB 6061 Alloy, 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
DB Gravel, 6061 Alloy, 8 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA IS-3/ No.11 Integrated Style
Seat
Saddle
Diamondback Performance Womens Gravel Road
Seatpost
DB Alloy, Micro Adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.52 mm | 1.54 mm |
| Front Center | 602 mm | 594 mm | 594 mm | 600 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 80 mm | 74 mm | 70 mm | 66 mm |
| Stack | 536 mm | 549 mm | 565 mm | 581 mm |
| Reach | 375 mm | 372 mm | 372 mm | 377 mm |
| Top Tube Length | 510 mm | 520 mm | 535 mm | 545 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 74 ° |
| Seat Tube Length | 395 mm | 425 mm | 455 mm | 485 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1026 mm | 1018 mm | 1018 mm | 1024 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 693 mm | 717 mm | 743 mm | 768 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Haanjenn 2 is part of the Diamondback Haanjenn model. 12 bikes variations carry this model name so far. You can easily view all of the Diamondback Haanjenn bikes models from 2019, here.
Model range prices
The most economical model, the Diamondback Haanjenn 1 2019 has a starting price of 599$. Diamondback Haanjenn 3 2019 on the other hand is the most expensive at 999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Commuter bikes
According to our math, the average price for a trustworthy Commuter bike is 762$. However, even though the average price of a Commuter bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Diamondback released this model in 2019, its price was 799$. In conclusion, this bike price is 4.86% higher than the price of the average Commuter bike.
Haanjenn 2 components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The wheels on Haanjenn 2 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Diamondback Haanjenn 2 has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 4 sizes. They vary from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, you won’t have a problem finding one that suits you.
