Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Women's Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Alloy, Formed Top Tube, 1 1/8" Headtube, Replaceable Hanger
Suspension Fork
DB Steel Gravel Disc, 1-1/8" Steerer Tube, w/Fender and Low Rider Mounts
Drivetrain
Rear Derailleur
Shimano Claris RD-R2000, 8 Speed, GS
Front Derailleur
Shimano Claris FD-R2000, 31.8mm Band Clamp
Shift Levers
Shimano Claris ST-R2000 STI, 2x8 Speed
Cassette
Shimano HG50 Cassette, 8 Speed, 11-32T
Crank
Alloy, Compact Cross, 46/34T
Bottom Bracket
Steel Cartridge
Chain
KMC Z8, 8 Speed
Pedals
DB Platform
Wheels
Front Hub
28h Alloy Quick Releaset
Rear Hub
28h Alloy Quick Release, Cassette
Rims
Diamondback Equation CX, 28h, Doublewall
Spokes
14g Stainless Steel
Tires
Diamondback Interval Wire Bead, 700x38c, Reflective Sidewall, 60TPI
Brakes
Brakes
Tektro Mira Post Mount Mechanical Disc, w/160mm Front / 140mm Rear Rotors
Brake Levers
Shimano Claris ST-2400
Cockpit
Stem
DB 6061 Alloy, 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
DB Gravel, 6061 Alloy, 8 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA IS-3/ No.11 Integrated Style
Seat
Saddle
Diamondback Performance Womens Gravel Road
Seatpost
DB Alloy, Micro Adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.48 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 278 mm | 278 mm |
| Front Center | 602 mm | 594 mm | 594 mm | 600 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 80 mm | 74 mm | 70 mm | 66 mm |
| Stack | 536 mm | 549 mm | 565 mm | 581 mm |
| Reach | 375 mm | 372 mm | 372 mm | 377 mm |
| Top Tube Length | 510 mm | 520 mm | 535 mm | 545 mm |
| Seat Tube Angle | 76 ° | 75 ° | 74 ° | 74 ° |
| Seat Tube Length | 395 mm | 425 mm | 455 mm | 485 mm |
| Head Tube Angle | 70 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 120 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1026 mm | 1018 mm | 1018 mm | 1024 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 74 mm | 74 mm |
| Standover Height | 693 mm | 717 mm | 743 mm | 768 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
Haanjenn 2 completes the Diamondback Haanjenn model. Diamondback released 12 bikes variations of this model so far. Take a sneak peek at all Diamondback Haanjenn bikes models from 2020, by clicking here.
Model range prices
The most economical model, the Diamondback Haanjenn 1 2020 has a starting price of 550$. Diamondback Haanjenn 3 2020 on the other hand is the most expensive at 1000$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter bikes average price
If you want an acceptable Commuter bike you should know that the average price is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 800$. If we compare this with the average Commuter bike cost we notice that the price is 4.99% higher.
Haanjenn 2 components
Fork material
The fork on this bike is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When it comes to wheels, the Haanjenn 2 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Haanjenn 2 has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
