Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Alloy, Formed Top Tube, Tapered Headtube, Replaceable Hanger
Suspension Fork
DB SPF Formed Alloy Gravel Disc w/ 1.5" Tapered Steerer Tube
Drivetrain
Rear Derailleur
Shimano Sora RD-R3000, 9 Speed
Front Derailleur
Shimano Sora FD-R3000, 31.8 Band Clamp
Shift Levers
Shimano Sora ST-R3000, 2x9 Speed
Cassette
Shimano HG400, 9 Speed Cassette, 11-32T
Crank
FSA Omega Adventure Mega, 46/30T
Bottom Bracket
FSA Mega Exo
Chain
KMC Z99, 9 Speed
Pedals
DB4L Alloy Platform
Wheels
Front Hub
28h Alloy Quick Releaset
Rear Hub
28h Alloy Quick Release, Cassette
Rims
Diamondback Equation, 28h, Doublewall
Spokes
14g Stainless Steel
Tires
WTB Riddler Comp, 700x37c
Brakes
Brakes
Tektro Lyra Flat Mount Mechanical Disc, w/ 160mm Front / 140mm Rear Rotors
Brake Levers
Shimano Sora ST-R3000
Cockpit
Stem
HED Eroica, 6061 Alloy, 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
HED Eroica, 7050 Alloy, 16 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA No.42, Sealed Cartridge
Seat
Saddle
DB Eldorado
Seatpost
HED Eroica, 6061 Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 53cm | 56cm | 59cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.55 mm | 1.6 mm | 1.66 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Stack | 556 mm | 583 mm | 606 mm | 634 mm |
| Reach | 380 mm | 376 mm | 378 mm | 382 mm |
| Top Tube Length | 532 mm | 547 mm | 567 mm | 587 mm |
| Seat Tube Angle | 74.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 475 mm | 505 mm | 535 mm | 565 mm |
| Head Tube Angle | 69 ° | 70 ° | 71 ° | 72 ° |
| Head Tube Length | 130 mm | 155 mm | 175 mm | 200 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1051 mm | 1048 mm | 1048 mm | 1051 mm |
| Standover Height | 761 mm | 784 mm | 821 mm | 852 mm |
| Wheels | 700 | 700 | 700 | 700 |
About this model
Haanjo 3 belongs to the Diamondback Haanjo model. 60 bikes variations carry this model name so far. You can easily view all of the Diamondback Haanjo bikes models from 2018, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2018 for 949$. If we compare this with the average Gravel bike cost we notice that the price is 159.43% lower.
Haanjo 3 components
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
As for the wheels, Diamondback Haanjo 3 2018, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Haanjo 3 is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
