Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork Suntour GVX
-
Groupset Apex, Praxis -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alloy Gravel Frame, Endurance Geometry, Fully Butted 6061-T6 Aluminum Formed Top Tube, Tapered Headtube, Flat Mount Disc, 142x12mm Thru-axle, Top Tube Bag Mounts, w/Replaceable Hanger
Suspension Fork
SR Suntour GVX32, 60mm Travel Suspension Fork, 12mm Thru Axle Drop Outs
Drivetrain
Rear Derailleur
SRAM Apex 1, 1x11 Speed
Shift Levers
SRAM Apex 1, 11 Speed, Double Tap 1x11 Speed, w/Left Dropper Remote Lever
Cassette
SRAM PG-1130 Cassette 11-42T, 11 Speed
Crank
Praxis Alba M24 38T
Bottom Bracket
Praxis M24 BSA
Chain
SRAM PC-1110, 11 Speed
Pedals
DB Resin Gravel Platform
Wheels
Front Hub
28h Aluminum Sealed Cartridge, Center Lock, 12mm Thru-axle
Rear Hub
28h Aluminum Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette
Rims
HED Tomcat Disc, 28h, 25mm Internal Width, Taped for Tubeless
Spokes
14 gauge Stainless Steel
Tires
WTB Raddler TCS Light, Dual DNA Compound, Lightweight Tubeless Casing, 700x44c
Brakes
Brakes
TRP Spyre C Flat Mount Mechanical Disc, w/160mm Front / 160mm Rear Rotors
Brake Levers
SRAM Apex 1
Cockpit
Stem
HED, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
HED, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA No.42, Sealed Cartridge
Seat
Saddle
WTB Gravelier, Cromoly Rail, 142x250
Seatpost
Kind Shock eTENi 27.2 Dropper, 65mm (XS,S,MD) 100mm (L,XL) travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.54 mm | 1.57 mm | 1.61 mm | 1.59 mm |
| Bottom Bracket Height | 278 mm | 278.5 mm | 279.5 mm | 279 mm | 279 mm |
| Front Center | 614 mm | 621 mm | 621 mm | 624 mm | 650 |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 80 mm | 74 mm | 72 mm | 67 mm | 68 mm |
| Stack | 556 mm | 578 mm | 591 mm | 609 mm | 633 mm |
| Reach | 367 mm | 376 mm | 377 mm | 379 mm | 397 mm |
| Top Tube Length | 517 mm | 532 mm | 547 mm | 572 mm | 597 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 380 mm | 450 mm | 500 mm | 535 mm | 565 mm |
| Head Tube Angle | 69 ° | 70 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm | 145 mm | 160 mm | 185 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1035 mm | 1042 mm | 1042 mm | 1046 mm | 1072 mm |
| Bottom Bracket Drop | 75 mm | 74 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 685 mm | 740 mm | 777 mm | 805 mm | 834 mm |
| Front Travel | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Haanjo 4 EXP is a Diamondback Haanjo model. 60 bikes variations carry this model name so far. You can easily view all of the Diamondback Haanjo bikes models from 2023, here.
Model range prices
Diamondback Haanjo 1 2023 is the most economical model, with a starting price of 785$. Diamondback Haanjo 8C 2023 on the other hand costs 5700$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 2200$. Comparing the average cost of a Gravel bike to this one, you will see that Haanjo 4 EXP price is 11.91% lower.
Overview of components
Fork
The Suntour GVX is included from the factory. It has a travel distance of 60mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The Haanjo 4 EXP 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Haanjo 4 EXP is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Diamondback Haanjo 4 EXP includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
