Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Apex AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alloy Gravel Frame, Endurance Geometry, Fully Butted 6061-T6 Aluminum Formed Top Tube, Tapered Headtube, Flat Mount Disc, 142x12mm Thru-axle, Top Tube Bag Mounts, w/Replaceable Hanger
Suspension Fork
DB Gravel Performance, Full Monocoque Carbon, Carbon 12mm Thru Axle Drop Outs, Flat Mount Disc ready, w/Tapered Steerer Tube
Drivetrain
Rear Derailleur
SRAM Apex AXS Eagle eTap, 12 Speed
Shift Levers
SRAM Apex AXS eTap, 12 Speed
Cassette
SRAM PG-1230 Eagle 11-50T, 12 Speed
Crank
SRAM Apex DUB Wide, 40T
Bottom Bracket
SRAM DUB BSA
Chain
SRAM Apex
Pedals
DB Resin Gravel Platform
Wheels
Front Hub
24h Aluminum Sealed Cartridge, Center Lock, 12mm Thru-axle
Rear Hub
24h Aluminum Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette
Rims
HED Tomcat Disc, 24h, 25mm Internal Width, Taped for Tubeless
Spokes
2.0/1.8/2.0 Butted Stainless Steel
Tires
WTB Vulpine, Dual DNA Compound, TCS Light Tubeless Casing 700x40c
Brakes
Brakes
SRAM Apex, Flat Mount Hydraulic Disc, w/160mm F / 160mm R, Rotors
Brake Levers
SRAM Apex Hydraulic
Cockpit
Stem
HED, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
HED, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA No.42, Sealed Cartridge
Seat
Saddle
WTB Gravelier, Cromoly Rail, 142x250
Seatpost
Kind Shock eTENi 27.2 Dropper, 65mm (XS,SM,MD) 100mm (LG,XL) travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.54 mm | 1.57 mm | 1.61 mm | 1.59 mm |
| Bottom Bracket Height | 278 mm | 278.5 mm | 279.5 mm | 279 mm | 279 mm |
| Front Center | 614 mm | 621 mm | 610 mm | 624 mm | 650 |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 80 mm | 74 mm | 82 mm | 67 mm | 68 mm |
| Stack | 556 mm | 578 mm | 591 mm | 609 mm | 633 mm |
| Reach | 367 mm | 376 mm | 377 mm | 379 mm | 397 mm |
| Top Tube Length | 517 mm | 532 mm | 547 mm | 572 mm | 597 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 380 mm | 450 mm | 500 mm | 535 mm | 565 mm |
| Head Tube Angle | 69 ° | 70 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm | 145 mm | 160 mm | 185 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1035 mm | 1042 mm | 1031 mm | 1046 mm | 1072 mm |
| Bottom Bracket Drop | 75 mm | 74 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 685 mm | 740 mm | 777 mm | 805 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Haanjo 5 belongs to the Diamondback Haanjo model. Diamondback launched 60 bikes of this model so far. Take a sneak peek at all Diamondback Haanjo bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Diamondback Haanjo 1 2023 has a starting price of 785$. Diamondback Haanjo 8C 2023 on the other hand is the most expensive at 5700$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Diamondback Haanjo 5 price was 2950$. Comparing the average cost of a Gravel bike to this one, you will see that Haanjo 5 price is 19.82% more expensive.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The wheels on Haanjo 5 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Haanjo 5 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Diamondback Haanjo 5 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Diamondback model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
