Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Custom Formed AL-6061 Heat Treated Aluminum with Progressive wheel Sizing (27.5" - XS,S) (29" - M,L,XL)
Suspension Fork
SR Suntour XCM-DS 100mm of Travel with Pre-Load Adjuster, for IS Post Mount Disc
Drivetrain
Rear Derailleur
Shimano Tourney TX800
Front Derailleur
Shimano Tourney TY500 Dual Pull
Shift Levers
Shimano M310 3x7 Speed Rapid Fire Shifter
Cassette
Shimano GH20 Cassette, 7speed, 12-32 Tooth
Crank
Shimano Tourney TY301,42/34/24t
Bottom Bracket
Sealed Cartridge Bearing
Chain
KMC Z7
Pedals
Wellgo Plastic Body
Wheels
Front Hub
Formula DC-20FQuick Release, 6 Bolt, Disc, Quick Release
Rear Hub
Formula DC-22-7RQuick Release, 6 Bolt, Disc, Quick Release
Rims
Aluminum MTB DDM-2 Double Wall, 32 hole
Spokes
Stainless Steel
Tires
Vee Tire Co. Rubber Rail Escape, 27.5x2.25 or 29x2.25"
Brakes
Brakes
Tektro M275 IS Post Mount, Hydraulic with 160mm Rotors F/R
Brake Levers
Tektro M275 Hydraulic
Cockpit
Stem
Aluminum MTB 31.8 Bar Bore Stem
Handlebar
Aluminum 31.8mm Bar, 25mm Rise
Grips
MTB Grip
Headset
1-1/8" Semi Integrated Cartridge Bearing
Seat
Saddle
MTB Saddle
Seatpost
Aluminum 27.2 Post with 15mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.55 mm | 1.55 mm | 1.5 mm | 1.46 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 630 mm | 655 mm | 660 mm | 687 mm | 713 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm |
| Trail | 99 mm | 99 mm | 85 mm | 84 mm | 85 mm |
| Stack | 582 mm | 591 mm | 611 mm | 625 mm | 639 mm |
| Reach | 360 mm | 382 mm | 395 mm | 416 mm | 437 mm |
| Top Tube Length | 534 mm | 559 mm | 584 mm | 609 mm | 634 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 440 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 110 mm | 95 mm | 110 mm | 125 mm |
| Chainstay Length | 419 mm | 419 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1044 mm | 1069 mm | 1091 mm | 1118 mm | 1144 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 714 mm | 744 mm | 779 mm | 803 mm | 838 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Hatch 3 belongs to the Diamondback Hatch model. Diamondback launched 9 bikes of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Diamondback Hatch 1 2021 has a starting price of 600$. Diamondback Hatch 3 2021 on the other hand is the most expensive at 700$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Diamondback released this model in 2021, its price was 700$. If we compare this with the average Crosscountry bike cost we notice that the price is 172.14% lower.
Overview of components
Fork
Diamondback Hatch 3 2021 bike is equipped with the SunTour XCM fork, and has 100mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When leaving the production line, the Hatch 3 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hatch 3 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
