Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Judy Gold RL
-
Groupset NX, Race Face -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mason 27.5" Plus 6061-T6 Weapons Grade Aluminum w/ Double Butted Formed Top Tube, Down Tube, Seatstays, Tapered Head Tube, ISCG-05 Tabs, 148x12mm Boost Dropouts, w/ Replaceable Hanger
Suspension Fork
Rockshox Judy Gold RL, 120mm Travel, Solo Air Spring, External Rebound Adjust w/ Turnkey Lockout, Magnesium Lowers, Alloy 1.5" Tapered Steerer Tube, Boost 110x15mm Thru-axle
Drivetrain
Rear Derailleur
SRAM NX, 11 Speed
Shift Levers
SRAM NX 11 Speed
Cassette
SRAM PG1130, 11 Speed, 11-42T
Crank
Raceface Æffect Cinch w/ Steel 28T "Narrow Wide"
Bottom Bracket
Raceface Outboard Bearing
Chain
KMC X11EL, 11 Speed
Pedals
DB4L Alloy Platform w/ Replaceable Pins
Wheels
Front Hub
32h Alloy, Boost 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
32h Alloy, Boost 148x12mm Thru-axle, 2 Sealed Cartridge Bearing, for SRAM XD w/ CNC Disc Mount
Rims
Diamondback Alex MD35, Tubeless ready, 32h
Spokes
14g Stainless Steel
Tires
Vee Rubber T-Fatty 27.5x2.8 tires
Brakes
Brakes
SRAM Level T Hydraulic Disc, w/ 180mm Front / Rear Centerline Rotors
Brake Levers
SRAM Level Hydraulic Levers
Cockpit
Stem
DB35 Alloy, 60mm, 35mm Bar Bore
Handlebar
DB35 Alloy, 760mm Wide, 15mm Rise, 35mm Bar Bore
Grips
DB "Flanged" Lock-on, 135mm Silcone
Headset
FSA NO.57, Sealed Cartridge for Tapered Headtube
Seat
Saddle
DB Race M-series Saddle
Seatpost
JD 7075 Alloy Internal Dropper, w/ 1x Lever, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.35 mm | 1.34 mm | 1.33 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 684 mm | 699 mm | 721 mm | 738 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 99 mm | 98 mm | 98 mm | 98 mm |
| Stack | 593 mm | 593 mm | 607 mm | 620 mm |
| Reach | 424 mm | 438 mm | 454 mm | 466 mm |
| Top Tube Length | 593 mm | 608 mm | 628 mm | 643 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1116 mm | 1131 mm | 1153 mm | 1170 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 730 mm | 755 mm | 791 mm | 826 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mason 2 is a Diamondback Mason model. Diamondback released 15 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Diamondback Mason 1 2020 is the most economical model, with a starting price of 1050$. Diamondback Mason 2 2020 on the other hand costs 1675$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2020 for 1675$. Comparing the average cost of a Trail bike to this one, you will see that Mason 2 price is 64.9% smaller.
Overview of components
Fork
The RockShox Judy Gold RL is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When leaving the production line, the Mason 2 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Mason 2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Diamondback Mason 2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Diamondback Mason 2 includes a dropper post. Therefore, climbing or descending will be a breeze.
