Diamondback Mission 2 Carbon 2022
2022 Mountain
Estimate price |
5,000$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 160mm -
Fork Fox Performance Float 36
-
Groupset X01 Eagle, Truvativ Descendant -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
New Mission Monocoque Carbon 160mm of Travel, Internal Cable Routing, Tapered Headtube, Threaded BB, ISCG-05 Tabs, Internal Dropper Post, 148x12mm Boost Hub Spacing, 27.5x2.6" ready, Post Mount Disc, w/ Replacable Hanger
Suspension Fork
Fox 36 Performance, 180mm Travel
Rear Shock
Fox Float X2 Performance Elite, Metric 230x65 Spacing
Drivetrain
Rear Derailleur
SRAM XO1 Eagle
Front Derailleur
N/A
Shift Levers
SRAM XO1 Eagle
Cassette
SRAM Eagle 10-50T
Crank
Truvativ Descendant 7K
Bottom Bracket
SRAM DUB
Chain
SRAM GX Eagle
Pedals
Diamondback CNC Alloy Sealed Pedal
Wheels
Front Hub
Raceface Vault
Rear Hub
Raceface Vault
Rims
Raceface ARC
Spokes
14G Stainless
Tires
Maxxis DHF 2.50 & Maxxis DHR II 2.40
Brakes
Brakes
SRAM Code R
Brake Levers
SRAM Code R
Cockpit
Stem
Raceface Atlas
Handlebar
Raceface Atlas
Grips
DB Lock-On Grip
Headset
FSA NO.57
Seat
Saddle
WTB Volt Pro
Seatpost
Kindshok E201 125mm (S) / 150mm (M,L) Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 347.5 mm | 347.5 mm | 347.5 mm |
| Front Center | 761 mm | 788 mm | 820 mm |
| Rake | 40 mm | 40 mm | 45 mm |
| Trail | 129 mm | 129 mm | 123 mm |
| Stack | 593 mm | 602 mm | 611 mm |
| Reach | 428 mm | 450 mm | 473 mm |
| Top Tube Length | 582 mm | 607 mm | 632 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 380 mm | 420 mm | 457 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1188 mm | 1215 mm | 1247 mm |
| Bottom Bracket Drop | 10 mm | 10 mm | 10 mm |
| Standover Height | 653 mm | 672 mm | 690 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Mission 2 Carbon completes the Diamondback Mission model. 15 bikes variations carry this model name so far. Take a sneak peek at all Diamondback Mission bikes models from 2022, by clicking here.
Model range prices
The most economical model, the Diamondback Mission 1 Carbon 2022 has a starting price of 4000$. Diamondback Mission Carbon 2 2022 on the other hand is the most expensive at 6100$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Diamondback released this model in 2022, its price was 5000$. Comparing this to the average Enduro bike price, we see that the price is 38.93% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The fork installed on this bike is the Fox Performance Float 36 model. The travel on this model is 180mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Mission 2 Carbon has a rear shock with a travel of 160mm. The model Fox Float X2 Performance Elite is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Mission 2 Carbon model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Mission 2 Carbon comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 3 sizes. They vary from 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Diamondback Mission 2 Carbon includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
