Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Acera, Shimano -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Overdrive 27.5" Butted 6061-T6 Aluminum, Formed Top / Down Tube, Machined Headtube, Forged Drop Outs w/ Replaceable Hanger
Suspension Fork
SR Suntour XCM-HLO Coil 27.5", 100mm Travel, 30mm Stanchions, Magnesium Lower, Alloy Crown w/ Hydraulic Speed Lock
Drivetrain
Rear Derailleur
Shimano Acera M3000, 9 Speed
Front Derailleur
Shimano MT400, Side Swing, Front Pull, Direct Mount
Shift Levers
Shimano Acera M3010 2x9 Speed Rapidfire
Cassette
Shimano HG201, 9 Speed Cassette, 11-36T
Crank
SR Suntour XCM, 36/22T
Bottom Bracket
Steel Cartridge
Chain
KMC Z99, 9 Speed
Pedals
DB4L Alloy Platform
Wheels
Front Hub
32h Alloy w/ CNC Disc Mount
Rear Hub
32h Alloy Cassette w/ CNC Disc mount
Rims
32h Diamondback SL-27.5 Doublewall
Spokes
14g Stainless Steel
Tires
Kenda Nevegal Lite, 27.5x 2.35"
Brakes
Brakes
Shimano BR-M315 Hydraulic Disc, w/ 180mm Front /160mm Rear Center Lock Rotors
Brake Levers
Shimano BR-M315 Hydraulic Lever w/ Reach Adjust
Cockpit
Stem
DB 3D Forged, 7° Rise, 31.8 Bar Bore
Handlebar
Diamondback, 740mm Wide, 15mm Rise, 31.8mm Bar Bore
Grips
New DB "Flanged" 135mm Silcone
Headset
FSA IS-3/NO.11 Integrated Style
Seat
Saddle
DB Race M-series Saddle
Seatpost
Alloy Micro Adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.43 mm | 1.42 mm | 1.42 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 660 mm | 688 mm | 709 mm | 732 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 98 mm | 97 mm | 98 mm | 97 mm |
| Stack | 568 mm | 586 mm | 604 mm | 623 mm |
| Reach | 391 mm | 411 mm | 426 mm | 440 mm |
| Top Tube Length | 567 mm | 593 mm | 613 mm | 633 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 410 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 418 mm | 418 mm | 418 mm | 418 mm |
| Wheelbase | 1074 mm | 1102 mm | 1123 mm | 1146 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 751 mm | 789 mm | 824 mm | 860 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Overdrive 2 completes the Diamondback Overdrive model. Diamondback released 37 bikes variations of this model so far. Take a sneak peek at all Diamondback Overdrive bikes models from 2018, by clicking here.
Model range prices
Diamondback Overdrive 1 2018 is the most affordable bike of this model and has a price of 499$. On the other hand, Diamondback Overdrive 29C 2 Carbon 2018, is the most expensive and costs 3399$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2018 for 699$. Comparing the average cost of a Crosscountry bike to this one, you will see that Overdrive 2 price is 172.53% lower.
Overview of components
Fork
This bike has the SunTour XCM HLO fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Overdrive 2 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Overdrive 2 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Diamondback Overdrive 2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
