Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Butted Aluminum for 27.5", Tapered Head Tube, Formed Top and Down Tube, w/ Integrated Disc Brake Tabs, Progressive Geometry, 148x12MM Thru-Axle for Maxxel
Suspension Fork
Rockshox Recon RL, Solo Air, 140mm Travel, 32mm Stanchions, 15mm Thru-axle, Tapered Steerer Tube, w/ Turn Key Lock out
Drivetrain
Rear Derailleur
SRAM SX 12 Speed
Shift Levers
SRAM SX Trigger 12 Speed
Cassette
SRAM SX 12 Speed 11-50T
Crank
SRAM SX Eagle w/ Steel 32T "Narrow Wide"
Bottom Bracket
Power Spline 73mm, 118mm Spindle
Chain
SRAM SX 12 Speed
Pedals
DB Alloy Platform w/ Replaceable Pins
Wheels
Front Hub
32h Alloy, 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
32h Alloy, Boost 148x12mm Thru-axle, 2 Sealed Cartridge Bearing, w/ CNC Disc Mount
Rims
Diamondback AL35, Tubeless compatible, 32h
Spokes
14g Stainless Steel
Tires
Vee Rubber Crown Gem 27.5x2.8
Brakes
Brakes
Shimano MT-500 Hydraulic Disc, w/ 180mm Front and 160mm Rear Rotors
Brake Levers
Shimano MT-500 Hydraulic
Cockpit
Stem
Race Face Chester, 40mm Reach, 35 Bar Bore
Handlebar
Race Face Chester, 780mm Wide, 35 Bar Bore
Grips
New DB "Flanged" Lock-on, 135mm Silcone
Headset
FSA NO.57, Sealed Cartridge for Tapered Headtube
Seat
Saddle
DB Sync'r Saddle
Seatpost
JD YSP18JL, Dropper post with Remote 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.33 mm | 1.32 mm | 1.3 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 707 mm | 723 mm | 743 mm | 764 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 112 mm | 113 mm | 112 mm | 112 mm |
| Stack | 587 mm | 587 mm | 601 mm | 614 mm |
| Reach | 426 mm | 443 mm | 456 mm | 472 mm |
| Top Tube Length | 594 mm | 609 mm | 628 mm | 648 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 460 mm | 510 mm | 560 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1139 mm | 1155 mm | 1175 mm | 1197 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 739 mm | 760 mm | 794 mm | 826 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Sync’r belongs to the Diamondback Syncr model. Diamondback released 19 bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
The most economical model, the Diamondback Sync’r 24 2022 has a starting price of 1050$. Diamondback Sync’r Carbon 29 2022 on the other hand is the most expensive at 3650$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 1500$. In conclusion, this bike price is 84.13% lower than the price of the average Trail bike.
Overview of components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Sync’r 2022 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sync’r comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Sync’r comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
