Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 80mm -
Fork SunTour XCM
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Aluminum Jr-24" Frame, Formed Tubing, Disc Specific w/ Replacable Hanger
Suspension Fork
SR Suntour XCM Boost 24" w/ 80mm Travel, 28mm Stanchions, 110x15mm Thru-Axle, w/ Preload Adjust
Drivetrain
Rear Derailleur
SRAM SX Eagle 12 Speed
Shift Levers
SRAM SX Eagle, Trigger, 12 Speed
Cassette
SRAM SX 12 Speed 11-50T
Crank
SRAM SX Eagle w/ Steel 30T "Narrow Wide"
Bottom Bracket
Truvativ Powerspline
Chain
SRAM SX 12 Speed
Pedals
DB4L Aluminum Platform
Wheels
Front Hub
32h Aluminum 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
32h Aluminum Boost 148x12mm Thru-axle, 2 Sealed Cartridge Bearing, for SRAM XD w/ CNC Disc Mount
Rims
Diamondback SL-240 Doublewall, 32h
Spokes
14g Stainless Steel
Tires
Vee Tire Crown Gem 24x2.6" Tires
Brakes
Brakes
Radius BH-960 Hydraulic Disc w/ 180mm Front / 160mm Rear Rotors
Brake Levers
Radius Hydraulic
Cockpit
Stem
Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore
Handlebar
Diamondback, 720mm Wide, 15mm Rise, 31.8 Bar Bore
Grips
DB "Flanged" 135mm Silcone
Headset
FSA IS-3/NO.11 Integrated Style
Seat
Saddle
DB Sync'r Jr. Saddle
Seatpost
DB Aluminum Micro Adjust, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.51 mm |
| Bottom Bracket Height | 306 mm |
| Front Center | 553 mm |
| Rake | 40 mm |
| Stack | 498 mm |
| Reach | 330 mm |
| Top Tube Length | 502 mm |
| Seat Tube Angle | 71 ° |
| Seat Tube Length | 317 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 412 mm |
| Wheelbase | 964 mm |
| Bottom Bracket Drop | 23 mm |
| Standover Height | 652 mm |
| Front Travel | 80 mm |
| Wheels | 24" |
Model Overview
Sync’r 24 completes the Diamondback Syncr model. Diamondback launched 19 bikes of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Diamondback Sync’r 24 2021 has a starting price of 1000$. Diamondback Sync’r Carbon 29 2021 on the other hand is the most expensive at 3650$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Mountain bikes
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, you could also get a good Mountain bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 1000$. Comparing the average cost of a Mountain bike to this one, you will see that Sync’r 24 price is 62.34% more expensive.
Overview of components
Fork
The Sync’r 24 comes factory-installed with the SunTour XCM fork. This has a travel range of 80mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on Sync’r 24 are the 24″ aluminum type. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sync’r 24 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
