Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 80mm -
Fork Suntour XCM
-
Groupset SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Aluminum Jr-24" Frame, Formed Tubing, Disc Specific w/ Replaceable Hanger
Suspension Fork
SR Suntour XCM Boost 24" w/ 80mm Travel, 28mm Stanchions, 110x15mm Thru-Axle, w/ Preload Adjust
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM SX Eagle 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM SX Eagle, Trigger, 12 Speed
Cassette
SRAM SX 12 Speed 11-50T
Crank
SRAM SX Eagle w/ Steel 30T "Narrow Wide"
Bottom Bracket
Truvativ Powerspline
Chain
SRAM SX 12 Speed
Pedals
DB4L Aluminum Platform
Wheels
Front Hub
32h Aluminum 100x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
32h Aluminum Boost 142x12mm Thru-axle, 2 Sealed Cartridge Bearing, for SRAM XD w/ CNC Disc Mount
Rims
Diamondback SL-240 Doublewall, 32h, Tubeless Compatible Rim, Not Taped
Spokes
14g Stainless Steel
Tires
Vee Tire Crown Gem 24x2.6" Tires, Non Tubeless Tire
Brakes
Brakes
Shimano MT200
Brake Levers
Shimano MT200
Cockpit
Stem
Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore
Handlebar
Diamondback, 720mm Wide, 15mm Rise, 31.8 Bar Bore
Grips
DB "Flanged" 135mm Silcone
Headset
FSA IS-3/NO.11 Integrated Style
Seat
Saddle
DB Sync'r Jr. Saddle
Seatpost
DB Aluminum Micro Adjust, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.51 mm |
| Bottom Bracket Height | 306 mm |
| Front Center | 553 mm |
| Rake | 40 mm |
| Stack | 498 mm |
| Reach | 330 mm |
| Top Tube Length | 502 mm |
| Seat Tube Angle | 71 ° |
| Seat Tube Length | 317 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 412 mm |
| Wheelbase | 964 mm |
| Bottom Bracket Drop | 23 mm |
| Standover Height | 652 mm |
| Front Travel | 80 mm |
| Wheels | 24" |
Model Overview
Sync’r 24 is a Diamondback Syncr model. Diamondback released 19 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Diamondback Sync’r 24 2023 is the most economical model, with a starting price of 1050$. Diamondback Sync’r Carbon 29 2023 on the other hand costs 3650$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Mountain bikes
According to our math, the average price for a trustworthy Mountain bike is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Diamondback Sync’r 24 price was 1050$. If we compare this with the average Mountain bike cost we notice that the price is 70.45% higher.
Sync’r 24 components
Fork
Diamondback Sync’r 24 2023 bike is equipped with the Suntour XCM fork, and has 80mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The Sync’r 24 2023 bike is equipped with 24″ aluminum wheels when leaving the factory. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sync’r 24 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
