Diamondback Sync’r Carbon 29 2020
2020 Mountain
Estimate price |
3,650$
Weight | 13.2 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Fork Fox Performance Float 34
-
Groupset GX Eagle, NX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Sync'r Monocoque Carbon, Asymetrical Chainstays, Internal Cable Routing, Tapered Headtube, Euro Standard Threaded BB, ISCG-05 Tabs, Internal Dropper Post Ready, 148x12mm Boost Hub Spacing, 29x2.4" as well as 27.5x2.6 compatable, Post Mount Disc, w/ Replacable Hanger
Suspension Fork
Fox 34 Performance Float, 140mm of Travel, Grip 3 POS, 15mm Thru Axle, for 29x2.4" can also fit **27.5x2.6" wheel / tire combinations
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12 Speed
Shift Levers
SRAM GX Eagle 12 Speed X-Actuation Trigger
Cassette
SRAM XG1275 Eagle, 12 Speed, 10-50T
Crank
SRAM NX, 32T Eagle Chainring
Bottom Bracket
Truvativ Powerspline
Chain
SRAM GX Eagle, 12 Speed
Pedals
DB4L Alloy Platform, Sealed Cartridge Bearings w/ Replaceable Pins
Wheels
Front Hub
32h Alloy, Boost 110x15mm Thru-axle, Sealed Cartridge Bearings, w/ CNC Disc Mount
Rear Hub
32h Alloy, Boost 148x12mm Thru-axle, 5 Sealed Cartridge Bearing, for SRAM XD Cassette, w/ CNC Disc Mount
Rims
Diamondback Blanchard 32R, Tubeless compatible, 32h
Spokes
14g Stainless Steel
Tires
Maxxis Minion DHF 29x2.5" EXO, TLR, Folding / Maxxis Minion DHR 29x2.4" EXO, TLR, Folding
Brakes
Brakes
Shimano MT501 Hydraulic Disc, w/ 180mm Front and 160mm Rear Rotors
Brake Levers
Shimano MT501 Hydraulic
Cockpit
Stem
Diamondback "Tec", 35mm Reach, 35mm Bar Bore
Handlebar
Race Face Æffect 35, 20mm Rise, 780mm Wide, 35mm Bar Bore
Grips
New DB "Flanged" Lock-on, 135mm Silcone
Headset
FSA No-57E Taper 1.5 /1-1/8" Standard Cups, Sealed Cartridge
Seat
Saddle
DB Sync'r Saddle
Seatpost
X-Fusion Manic Dropper Post, 125mm (S,M) / 150mm (L,XL) of travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.424 mm | 1.37 mm | 1.341 mm | 1.314 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 708 mm | 735 mm | 755 mm | 774 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 116 mm | 116 mm | 119 mm | 121 mm |
| Stack | 591 mm | 600 mm | 610 mm | 620 mm |
| Reach | 415 mm | 438 mm | 455 mm | 472 mm |
| Top Tube Length | 585 mm | 610 mm | 630 mm | 650 |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 435 mm | 485 mm | 535 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1138 mm | 1165 mm | 1185 mm | 1204 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 754 mm | 772 mm | 808 mm | 842 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Sync’r Carbon 29 belongs to the Diamondback Syncr model. There are 19 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Diamondback Sync’r 24 2020 is the cheapest bike model and costs 1000$. Diamondback Sync’r Carbon 29 2020 is the most expensive one and costs 3650$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3650$. Comparing the average cost of a Trail bike to this one, you will see that Sync’r Carbon 29 price is 32.15% more expensive.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 13.2 kg (29.1 lbs), the Sync’r Carbon 29 model is slightly heavier than average. In short, the average Trail bike weight is 1.69% lower than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Sync’r Carbon 29 components
Fork
The Sync’r Carbon 29 comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
The wheels on Sync’r Carbon 29 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Diamondback Sync’r Carbon 29 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
