Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork Fox Performance Float 34
-
Groupset XT, Race Face -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 Butted Alloy for 27.5", Tapered Head Tube, Formed Top and Down Tube, w/ Integrated Disc Brake Tabs, Progressive Geometry, Boost 148x12MM Thru-axle for Maxel
Suspension Fork
Fox Performance 34 Float 27.5", 130mm Travel, Open Cartridge, 3 Position Lever w/ External Rebound Adjust, 1.5" Butted Alloy Tapered Steerer Tube, 34mm Easton Aluminum Stanchions, w/ 15mm Thru-axle
Drivetrain
Rear Derailleur
Shimano XT M8000, Shadow Plus, 11 Speed
Shift Levers
Shimano XT M8000, I-Spec, 11 Speed
Cassette
Shimano XT M8000, Cassette, 11 Speed, 11-42T
Crank
Raceface Æffect, 32T Direct Mount "Narrow Wide" Single Ring, Boost Compatible
Bottom Bracket
Raceface Outboard Bearing
Chain
KMC X11, 11 Speed
Pedals
DB4L Alloy Platform
Wheels
Front Hub
32h Alloy,15mm Thru-axle, w/ CNC Disc Mount
Rear Hub
32h Alloy, Boost 148x12mm Thru-axle, 4 Sealed Cartridge Bearing, Cassette
Rims
Diamondback Blanchard 28R, Tubeless Compatible, 32h
Spokes
14g Stainless Steel
Tires
WTB Vigilante Comp, 27.5x2.3"
Brakes
Brakes
Shimano M447 Hydraulic Disc w/ 180mm Front / 160mm Rear Rotors
Brake Levers
Shimano M506 Hydraulic Disc Alloy Levers
Cockpit
Stem
Diamondback "Shortie", 50mm Reach, 35mm Bar Bore
Handlebar
Race Face Æffect 35, 20mm Rise, 760mm Wide, 35mm Bar Bore
Grips
DB4L "Lock on" 135mm Kraton
Headset
FSA No-57E Taper 1.5 /1-1/8" Standard Cups, Sealed Cartridge
Seat
Saddle
DB Sync'r Saddle
Seatpost
Kindshock eTen Integera, 100mm Internal Dropper, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 575 mm | 600 mm | 620 mm | 640 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 165 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1090 mm | 1118 mm | 1140 mm | 1163 mm |
| Standover Height | 714 mm | 751 mm | 775 mm | 814 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Sync’r Pro completes the Diamondback Syncr model. Diamondback launched 19 bikes of this model so far. Take a sneak peek at all Diamondback Syncr bikes models from 2017, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
Diamondback Sync’r Pro 2017 bike is equipped with the Fox Performance Float 34 fork, and has 130mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
Sync’r Pro has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the Sync’r Pro bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Sync’r Pro comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Diamondback Sync’r Pro includes a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
