Eddy Merckx Strasbourg Steel Sram Apex1 1×11 2023
2023 Road
Estimate price |
2,093$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Apex -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Strasbourg Steel 7E7/size M/SBS01Bs
Suspension Fork
Forza Oryx Disc, TA 12x100mm
Drivetrain
Rear Derailleur
SRAM Apex1 // Long Cage
Cassette
SRAM PG-1130 // 11s // 11-42
Crank
SRAM Apex1 // 42T // 172mm
Pedals
Not included **
Wheels
Rims
Shimano RS171 DB // Shimano 11s // Clincher
Tires
Vittoria Terreno Dry // 700x38c
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Forza Stratos // 100 mm // Black Glossy
Handlebar
4ZA Stratos Gravel 420/480
Seat
Saddle
Selle San Marco Shortfit Wide
Seatpost
Forza Stratos // 15mm Offset // 350mm // 27,2mm // Black Glossy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.5 mm | 1.54 mm | 1.55 mm |
| Bottom Bracket Height | 277 mm | 279 mm | 276 mm | 278 mm | 278 mm |
| Front Center | 589 mm | 595 mm | 601 mm | 616 mm | 632 mm |
| Rake | 50 mm | 50 mm | 52 mm | 50 mm | 50 mm |
| Trail | 67 mm | 64 mm | 59 mm | 61 mm | 61 mm |
| Stack | 535 mm | 554 mm | 574 mm | 599 mm | 618 mm |
| Reach | 374 mm | 379 mm | 382 mm | 390 mm | 400 mm |
| Top Tube Length | 527 mm | 537 mm | 552 mm | 567 mm | 582 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 470 mm | 495 mm | 520 mm | 545 mm | 570 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 105 mm | 125 mm | 145 mm | 170 mm | 190 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1005 mm | 1012 mm | 1017 mm | 1033 mm | 1049 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 73 mm | 71 mm | 71 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Strasbourg Steel Sram Apex1 1×11 is an Eddymerckx Strasbourg model. Eddy Merckx released 7 bikes variations of this model so far. You can easily view all of the Eddymerckx Strasbourg bikes models from 2023, here.
Model range prices
Eddy Merckx Strasbourg Steel Sram Apex1 1×11 2023 is the most affordable bike of this model and has a price of 1910$. On the other hand, Eddy Merckx Strasbourg Carbon Shimano GRX800 DI2 1x11sp 2023, is the most expensive and costs 4512$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Eddy Merckx Strasbourg Steel Sram Apex1 1×11 price was 1910$. Comparing this to the average Gravel bike price, we see that the price is 28.9% lower.
Strasbourg Steel Sram Apex1 1×11 components
Wheels size
When it comes to wheels, the Strasbourg Steel Sram Apex1 1×11 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Eddy Merckx Strasbourg Steel Sram Apex1 1×11 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Eddy Merckx Strasbourg Steel Sram Apex1 1×11 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
