Ellsworth Truth Convert SRAM GX 27.5″+ 2018
2018 Mountain
Estimate price |
6,145$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Factory Float 32
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
100mm: FOX 32 Float 29 SC Factory, 120mm: FOX 34 Float 29 Factory
Rear Shock
FOX Float DPS Factory
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
N/A
Shift Levers
SRAM GX, 12-speed
Cassette
SRAM GX, 11-50 tooth, 12-speed
Crank
SRAM GX Boost
Bottom Bracket
SRAM GXP, threaded
Chain
SRAM GX
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss M1900, Boost front and rear
Rear Hub
DT Swiss M1900, Boost front and rear
Rims
DT Swiss M1900, 35mm width
Spokes
DT Swiss
Tires
Maxxis Ikon, 27.5" x 2.8"
Brakes
Brakes
Shimano SLX 7000 with Shimano SM-RT70 180mm front/160mm rear rotors
Brake Levers
Shimano SLX 7000
Cockpit
Stem
Race Face Evolve, 70mm length, 6mm rise, 31.8mm clamp
Handlebar
Race Face Evolve, 725mm width, 31.8mm diameter, 20mm rise
Grips
Lizard Skin Charger
Headset
Cane Creek 10 Series ZS44/56
Seat
Saddle
WTB Volt Pro
Seatpost
FOX Transfer Dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm |
| Stack | 583 mm | 592 mm | 602 mm |
| Reach | 418 mm | 443 mm | 467 mm |
| Top Tube Length | 570 mm | 598 mm | 625 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 98 mm | 109 mm | 120 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1116 mm | 1145 mm | 1174 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm |
| Standover Height | 627 mm | 627 mm | 627 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Truth Convert SRAM GX 27.5″+ is part of the Ellsworth Truth model. There are 10 bikes that carry this model name. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
Ellsworth Truth Convert SRAM GX 27.5″+ 2018 is the most affordable bike of this model and has a price of 6145$. On the other hand, Ellsworth Truth Convert SRAM XX1 Eagle 29″ 2018, is the most expensive and costs 8795$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Ellsworth Truth Convert SRAM GX 27.5″+ price was 6145$. Comparing this to the average Crosscountry bike price, we see that the price is 222.57% more expensive.
Truth Convert SRAM GX 27.5″+ components
Fork
The Truth Convert SRAM GX 27.5″+ comes factory-installed with the Fox Factory Float 32 fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the FOX Float DPS Factory model, with a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the Truth Convert SRAM GX 27.5″+ model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Truth Convert SRAM GX 27.5″+ has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Ellsworth Truth Convert SRAM GX 27.5″+ includes a dropper post. Therefore, climbing or descending will be a breeze.
