Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Fork Cane Creek HELM
-
Groupset GX Eagle, SRAM -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
Cane Creek Helm, 44mm offset
Rear Shock
Cane Creek DB Air Inline, 210mm x 55mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 12-speed
Front Derailleur
None
Shift Levers
SRAM Eagle, 12-speed
Cassette
SRAM GX Eagle XG-1275, 12-speed
Crank
SRAM GX Eagle DUB
Bottom Bracket
SRAM DUB, BB92 PressFit
Chain
SRAM NX Eagle, 12-speed
Chain Guide
MRP 1x CS upper slider
Pedals
None
Wheels
Front Hub
Crankbrothers Synthesis Enduro wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rear Hub
Crankbrothers Synthesis Enduro wheelset, 110x15mm Boost front, 148x12mm Boost rear with XD driver
Rims
Crankbrothers Synthesis Enduro Alloy wheelset
Spokes
Crankbrothers Synthesis Enduro Alloy wheelset
Tires
Front: Vittoria Mazza, 29" x 2.6", Rear: Vittoria Martello, 29" x 2.35"
Brakes
Brakes
TRP Slate, 4-piston, TRP rotors (203mm front, 180mm rear)
Brake Levers
TRP Slate
Cockpit
Stem
Valiant, 50mm length
Handlebar
ProTaper aluminum, 810mm width
Grips
Lizard Skins Charger Evo
Headset
ACROS Block Lock, steel, ZS44/ZS56
Seat
Saddle
WTB Volt Comp
Seatpost
KS Rage dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.47 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Stack | 621 mm | 631 mm | 640 mm | 650 |
| Reach | 405 mm | 430 mm | 458 mm | 488 mm |
| Top Tube Length | 570 mm | 599 mm | 627 mm | 652 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 76 ° |
| Seat Tube Length | 432 mm | 451 mm | 471 mm | 471 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1156 mm | 1185 mm | 1214 mm | 1252 mm |
| Bottom Bracket Drop | 37 mm | 37 mm | 37 mm | 37 mm |
| Standover Height | 736 mm | 736 mm | 736 mm | 736 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Onset LT GX 29 is an Eminent Onset model. Eminent released 31 bikes variations of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Eminent Onset ST Comp 29 2021 is the cheapest bike model and costs 4699$. Eminent Onset MT Pro 29 2021 is the most expensive one and costs 8599$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2021 for 5499$. Doing a quick comparison, we notice that Onset LT GX 29 price is 99.09% more expensive than the average cost of a Trail bike.
Onset LT GX 29 components
Fork
The Cane Creek HELM is included from the factory. It has a travel distance of 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Cane Creek DB Air Inline model, with a travel of 140mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The Onset LT GX 29 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Eminent Onset LT GX 29 comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
