Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Factory Float 34
-
Groupset XTR -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
FOX FLOAT 34 Factory, FIT4 damper, 44mm offset
Rear Shock
FOX FLOAT DPS Factory, 190mm x 45mm
Drivetrain
Rear Derailleur
Shimano XTR M9120, 12-speed
Front Derailleur
None
Shift Levers
Shimano XTR M9100, 12-speed
Cassette
Shimano XTR M9100, 12-speed, 10-51 tooth
Crank
Shimano XTR M9120
Bottom Bracket
Shimano, BB92 press-fit
Chain
Shimano XTR M9100, 12-speed
Chain Guide
MRP 1x CS upper slider
Pedals
None
Wheels
Front Hub
Industry Nine, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rear Hub
Industry Nine, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Rims
Crankbrothers Synthesis XCT Carbon
Tires
Vittoria Martello, 29" x 2.35"
Brakes
Brakes
Shimano XTR M9100, 2-piston, Shimano RT66 rotors (203mm front, 180mm rear)
Brake Levers
Shimano XTR M9100
Cockpit
Stem
Valiant, 50mm length
Handlebar
ProTaper carbon, 810mm width
Grips
Lizard Skins Charger Evo
Headset
ACROS Block Lock, stainless steel, ZS44/ZS56
Seat
Saddle
WTB Volt Pro
Seatpost
KS Rage dropper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.42 mm | 1.36 mm | 1.29 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Stack | 615 mm | 624 mm | 633 mm | 642 mm |
| Reach | 414 mm | 439 mm | 465 mm | 498 mm |
| Top Tube Length | 566 mm | 595 mm | 625 mm | 648 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 77 ° |
| Seat Tube Length | 432 mm | 451 mm | 471 mm | 471 mm |
| Head Tube Angle | 66.8 ° | 66.8 ° | 66.8 ° | 66.8 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1148 mm | 1177 mm | 1207 mm | 1244 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 44 mm | 44 mm |
| Standover Height | 729 mm | 729 mm | 729 mm | 729 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Onset ST Pro 29 is part of the Eminent Onset model. 31 bikes variations carry this model name so far. You can easily view all of the Eminent Onset bikes models from 2021, here.
Model range prices
Eminent Onset ST Comp 29 2021 is the most economical model, with a starting price of 4699$. Eminent Onset MT Pro 29 2021 on the other hand costs 8599$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2021 for 8299$. Doing a quick comparison, we notice that Onset ST Pro 29 price is 200.47% more expensive than the average cost of a Trail bike.
Onset ST Pro 29 components
Fork
Eminent Onset ST Pro 29 2021 bike is equipped with the Fox Factory Float 34 fork, and has 130mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Eminent Onset ST Pro 29 bike has the FOX FLOAT DPS Factory model installed, and has a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
As for the wheels, Eminent Onset ST Pro 29 2021, has a 29″ carbon model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Eminent Onset ST Pro 29 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Eminent Onset ST Pro 29 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
