Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Evil Chamois Hagar UD Carbon, Internal Routing, 142x12, Flat Mount Road, Braze-On Adapter
Suspension Fork
Evil Carbon Chamois Hagar Fork, 12x100mm Thru-Axle, Flat Mount Brakes
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano RD-RX812, GRX, 11sp, Shadow+
Front Derailleur
Braze On
Shift Levers
Shimano GRX Left: ST-RX810-LA "dropper", Right: ST-RX810-R
Cassette
Shimano CS-M8000,DEORE XT, 11-SPEED, 11-13-15-17-19-21-24-28-32-37-46
Crank
Shimano FC-RX810-1, GRX, 172.5MM, 40T
Bottom Bracket
68mm Threaded
Chain
Shimano CN-HG701-11
Wheels
Rims
N/A
Tires
Front: WTB Venture 700x50c TCS, w/ Black Wall, Rear: WTB Venture 700x50c TCS, w/ Black Wall
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Evil Stem, Length:50mm, Clamp:31.8
Handlebar
EASTON EA70 AX,Reach 80mm, Drop 120mm, Flare 16?, S/M 44cm, L/XL 46cm
Grips
Evil Gravel Tape w/Gel
Headset
CaneCreek 40-Series, Bearing: 36° x 45° - 41mm (upper) and 36° x 45° - 52mm (Lower) ZN40 Zinc Coated (no race) w/compression preload plug
Seat
Saddle
WTB Volt Medium (142mm) Width Chromoly Saddle
Seatpost
Bike Yoke Revive, 30.9, S: 125mm, M/L: 160mm, XL: 185mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.42 mm | 1.39 mm | 1.37 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 278 mm | 278 mm |
| Front Center | 680 mm | 708 mm | 736 mm | 764 mm |
| Rake | 57 mm | 57 mm | 57 mm | 57 mm |
| Trail | 93 mm | 93 mm | 93 mm | 93 mm |
| Stack | 574 mm | 593 mm | 611 mm | 630 mm |
| Reach | 399 mm | 419 mm | 439 mm | 459 mm |
| Top Tube Length | 585 mm | 604 mm | 623 mm | 642 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 74 ° | 74.5 ° |
| Seat Tube Length | 450 mm | 470 mm | 490 mm | 510 mm |
| Head Tube Angle | 66.67 ° | 66.67 ° | 66.67 ° | 66.67 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1097 mm | 1125 mm | 1153 mm | 1181 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 661 mm | 670 mm | 681 mm | 695 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Chamois Hagar / GRX is part of the Evil Chamois model. 11 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Evil Chamois Hagar / GRX 2022, has a 700c model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Evil Chamois Hagar / GRX is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Chamois Hagar / GRX comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
The Evil model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
