Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GX Eagle AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Evil Chamois Hagar UD Carbon, Internal Routing, 142x12, Flat Mount Road, Braze-On Adapter
Suspension Fork
Evil Carbon Chamois Hagar Fork, 12x100mm Thru-Axle, Flat Mount Brakes
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM GX AXS Lunar
Front Derailleur
Braze On
Shift Levers
SRAM Rival eTap AXS HRD Shift-Brake
Cassette
SRAM GX 10-52 Lunar
Crank
SRAM Force 1 Carbon, DUB, 38t, 172.5mm
Bottom Bracket
68mm Threaded
Chain
SRAM GX Eagle w/Powerlock
Wheels
Rims
N/A
Tires
Front: WTB Venture 700x50c TCS, w/ Black Wall, Rear: WTB Venture 700x50c TCS, w/ Black Wall
Brakes
Brakes
SRAM Rival eTap, Flat Mount
Cockpit
Stem
Evil Stem, Length:50mm, Clamp:31.8
Handlebar
EASTON EA70 AX,Reach 80mm, Drop 120mm, Flare 16?, S/M 44cm, L/XL 46cm
Grips
Evil Gravel Tape w/Gel
Headset
CaneCreek 40-Series, Bearing: 36° x 45° - 41mm (upper) and 36° x 45° - 52mm (Lower) ZN40 Zinc Coated (no race) w/compression preload plug
Seat
Saddle
WTB Volt Medium (142mm) Width Chromoly Saddle
Seatpost
SRAM AXS Reverb, 30.9, S: 125mm, M: 150mm, L/XL: 170mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.42 mm | 1.39 mm | 1.37 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 278 mm | 278 mm |
| Front Center | 680 mm | 708 mm | 736 mm | 764 mm |
| Rake | 57 mm | 57 mm | 57 mm | 57 mm |
| Trail | 93 mm | 93 mm | 93 mm | 93 mm |
| Stack | 574 mm | 593 mm | 611 mm | 630 mm |
| Reach | 399 mm | 419 mm | 439 mm | 459 mm |
| Top Tube Length | 585 mm | 604 mm | 623 mm | 642 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 74 ° | 74.5 ° |
| Seat Tube Length | 450 mm | 470 mm | 490 mm | 510 mm |
| Head Tube Angle | 66.67 ° | 66.67 ° | 66.67 ° | 66.67 ° |
| Head Tube Length | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1097 mm | 1125 mm | 1153 mm | 1181 mm |
| Bottom Bracket Drop | 80 mm | 80 mm | 80 mm | 80 mm |
| Standover Height | 661 mm | 670 mm | 681 mm | 695 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Chamois Hagar / – Rival AXS is part of the Evil Chamois model. There are 11 bikes that carry this model name. Take a sneak peek at all Evil Chamois bikes models from 2022, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Chamois Hagar / – Rival AXS components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, Evil Chamois Hagar / – Rival AXS 2022, has a 700c model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Evil Chamois Hagar / – Rival AXS has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Evil Chamois Hagar / – Rival AXS includes a dropper post. Therefore, climbing or descending will be a breeze.
