Evil Faction II / Faction 2 – Complete Build Kit 2022
2022 Mountain
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Pike DJ
-
Suspension Hardtail -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
EVIL Faction II, 4130 Chromoly
Suspension Fork
Rockshox Pike DJ, 100mm Travel, 40mm Offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
N/A
Shift Levers
N/A
Cassette
Novatec 9t Driver
Crank
Sammox 3-piece Chromoly, 19mm, 48-spline
Bottom Bracket
Mid Type BB
Chain
KMC HL1 Wide, Black, Half-Link
Wheels
Rims
26
Tires
Front: 'Skinwall, '26X2.30 M147P DTH F60 SC SK, Clincher,, Rear: 'Skinwall, '26X2.30 M147P DTH F60 SC SK, Clincher,
Brakes
Brakes
Mechanical Disc
Cockpit
Stem
Evil 12 Gauge Stem / Length: 45mm
Handlebar
Evil Boomstick 7075 Alloy, Backsweep: 8°, Upsweep: 5° Clamp:35mm, Rise: 35mm, Width: 810mm
Grips
Evil Lock-on
Headset
FSA Faction II, Integrated
Seat
Saddle
SDG Apollo Black Synthetic/Grey Icon
Seatpost
SDG Micro I-Beam
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.34 mm | 1.3 mm | 1.26 mm |
| Bottom Bracket Height | 323 mm | 323 mm | 323 mm |
| Stack | 526 mm | 526 mm | 526 mm |
| Reach | 394 mm | 404 mm | 419 mm |
| Top Tube Length | 585 mm | 595 mm | 610 mm |
| Seat Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 320 mm | 320 mm | 320 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 115 mm | 115 mm | 115 mm |
| Chainstay Length | 386 mm | 386 mm | 386 mm |
| Wheelbase | 1021 mm | 1031 mm | 1046 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Faction II / Faction 2 – Complete Build Kit is an Evil Faction model. Evil launched 8 bikes of this model so far. You can easily view all of the Evil Faction bikes models from 2022, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Dirt Jump bikes
If you want to purchase a solid Dirt Jump bike, it is important to know that the average cost is 863$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Dirt Jump bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Faction II / Faction 2 – Complete Build Kit components
Fork
The Faction II / Faction 2 – Complete Build Kit comes factory-installed with the RockShox Pike DJ fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the Faction II / Faction 2 – Complete Build Kit bike is equipped with the 26″ aluminum model. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Evil Faction II / Faction 2 – Complete Build Kit has Mechanical Disc brakes installed. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
