Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra 2023
2023 Mountain
Estimate price |
10,321$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 180mm -
Travel Rear 168mm -
Fork RockShox ZEB Ultimate
-
Groupset X01 Eagle AXS -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Insurgent 168mm of travel, UD Carbon, Full Internal Cable Routing, SB+ 157mm Rear Spacing Integrated Chain Guide, Threaded BB, UDH Compatible
Suspension Fork
Rockshox Zeb Ultimate, Charger 3 RC2 W/ ButterCups, 27.5”, 180mm Travel, 44mm Offset
Rear Shock
Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, LN L1 HB 38TS, S/M: 350lbs, L/XL 400lbs
Drivetrain
Rear Derailleur
SRAM X01 AXS Eagle Transmission Derailleur
Shift Levers
SRAM AXS Controller
Cassette
SRAM X01 Eagle XG1295 10-52T
Crank
SRAM X01 Eagle Lunar Polar DUB carbon, 32t ring, 170mm
Bottom Bracket
SRAM DUB 73mm BSA, 7.5mm Spacer Drive/3mm Spacer Non-Drive
Chain
SRAM GX Eagle w/Powerlock
Wheels
Rims
Industry Nine Enduro S Hydra 27.5 Internal Width: 30.5mm, Hub: 110x15mm
Tires
Maxxis Minion DHF EXO TR, 27.5x2.5
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Evil 12 Gauge, Clamp: 35mm, Length: 45mm
Handlebar
Evil Boomstick Carbon, Backsweep: 8°, Upsweep 5° Clamp:35mm, Rise: 35mm, Width: 810mm
Grips
Evil Palmela Handerson lock-on
Headset
Works Components 1 Degree Angleset
Seat
Saddle
WTB Volt Pro
Seatpost
Bike Yoke Revive, S:125mm, M: 160mm, L:185m XL: 213mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM Low | SM Low | MD Low | MD Low | LG Low | LG Low | XL Low | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.432 mm | 1.402 mm | 1.402 mm | 1.37 mm | 1.368 mm | 1.338 mm | 1.335 mm | 1.304 mm |
| Bottom Bracket Height | 349 mm | 358 mm | 349 mm | 358 mm | 349 mm | 358 mm | 349 mm | 358 mm |
| Front Center | 785 mm | 785 mm | 806 mm | 806 mm | 832 mm | 832 mm | 857 mm | 857 mm |
| Rake | 36 mm | 38 mm | 36 mm | 38 mm | 36 mm | 38 mm | 36 mm | 38 mm |
| Trail | 136 mm | 131 mm | 136 mm | 131 mm | 136 mm | 131 mm | 136 mm | 131 mm |
| Stack | 626 mm | 621 mm | 635 mm | 630 mm | 647 mm | 642 mm | 658 mm | 652 mm |
| Reach | 437 mm | 443 mm | 453 mm | 460 mm | 473 mm | 480 mm | 493 mm | 500 mm |
| Top Tube Length | 598 mm | mm | 615 mm | mm | 636 mm | mm | 657 mm | mm |
| Seat Tube Angle | 76.2 ° | 76.9 ° | 76.2 ° | 76.9 ° | 76.2 ° | 76.9 ° | 76.2 ° | 76.9 ° |
| Head Tube Angle | 63.5 ° | 64.2 ° | 63.5 ° | 64.2 ° | 63.5 ° | 64.2 ° | 63.5 ° | 64.2 ° |
| Chainstay Length | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm |
| Wheelbase | 1217 mm | 1215 mm | 1238 mm | 1236 mm | 1264 mm | 1262 mm | 1289 mm | 1287 mm |
| Bottom Bracket Drop | 8 mm | 1 mm | 8 mm | 1 mm | 8 mm | 1 mm | 8 mm | 1 mm |
| Standover Height | 699 mm | 705 mm | 709 mm | 716 mm | 718 mm | 724 mm | 718 mm | 736 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
Insurgent LS SRAM X01 AXS Eagle I9 Hydra completes the Evil Insurgent model. Evil launched 48 bikes of this model so far. You can easily view all of the Evil Insurgent bikes models from 2023, here.
Model range prices
The most economical model, the Evil Insurgent – LS SRAM GX MECHANICAL i9 HYDRA MX 2023 has a starting price of 6999$. Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra 2023 on the other hand is the most expensive at 9555$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Enduro bikes average price
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, this doesn’t mean that if you spend less money on an Enduro bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 9555$. Comparing this to the average Enduro bike price, we see that the price is 165.49% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The fork installed on this bike is the RockShox ZEB Ultimate model. The travel on this model is 180mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra bike has the Rockshox Super Deluxe Coil Ultimate model installed, and has a travel of 168mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When leaving the production line, the Insurgent LS SRAM X01 AXS Eagle I9 Hydra model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Insurgent LS SRAM X01 AXS Eagle I9 Hydra comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
Evil Insurgent LS SRAM X01 AXS Eagle I9 Hydra comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
