Evil Wreckoning LS SRAM X0 Eagle T-TYPE I9 HYDRA (Custom Order) 2023
2023 Mountain
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 170mm -
Travel Rear 166mm -
Fork RockShox ZEB Ultimate
-
Groupset X0 Eagle Transmission, SRAM -
Suspension Full -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Wreckoning LS 166mm of travel, UD Carbon, Full Internal Cable Routing, SB+ 157mm Rear Spacing, Integrated Chain Guide, Threaded BB, UDH Compatible
Suspension Fork
Rockshox Zeb Ultimate, Charger 3 RC2 W/ ButterCups, 170mm Travel, 44mm Offset
Rear Shock
Rockshox Super Deluxe Coil Ultimate, Trunnion 205x65, LN L1 HB 38TS, S/M: 350lbs, L/XL 400lbs
Drivetrain
Rear Derailleur
SRAM X0 Eagle Transmission Derailleur
Shift Levers
SRAM AXS Pod Controller
Cassette
SRAM X0 Eagle Transmission Cassette, 10-52T, 10, 12, 14, 16, 18, 21, 24, 28, 32, 38, 44, 52
Crank
SRAM X0 Eagle Crankset, DUB, 170mm, Direct Mount 32t, 55mm Chainline, Aluminum
Bottom Bracket
SRAM DUB 73mm BSA, 7.5mm Spacer Drive/3mm Spacer Non-Drive
Chain
SRAM X0 Eagle Transmission Flat Top Chain w/Powerlock, 116 Link
Wheels
Rims
Industry Nine Enduro S Hydra Internal Width: 30.5mm, Hub: 110x15mm
Tires
Maxxis Minion DHF EXO TR, 29x2.5
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Evil 12 Gauge, Clamp: 35mm, Length: 45mm
Handlebar
Evil Boomstick Carbon, Backsweep: 8°, Upsweep 5° Clamp:35mm, Rise: 35mm, Width: 810mm
Grips
Evil Palmela Handerson lock-on
Headset
Cane Creek 40 Series ZS Integrated Tapered Headset - Cups: ZS44/28.6 (Upper) and ZS62/40(Lower), Bearing: 36° x 45° - 41mm (Upper) and 36° x 45° - 52mm (Lower) ZN40 Zinc Coated, Crown Race: 28.6mm x 36° Integrated (Upper) and 40mm x 36° Press Fit (Lower)
Seat
Saddle
WTB Volt Pro
Seatpost
Bike Yoke Revive, S:125mm, M: 160mm, L:185m XL: 213mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM Low | SM Low | MD Low | MD Low | LG Low | LG Low | XL Low | XL Low |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.429 mm | 1.464 mm | 1.396 mm | 1.461 mm | 1.362 mm | 1.393 mm | 1.329 mm | 1.359 mm |
| Bottom Bracket Height | 355 mm | 347 mm | 355 mm | 347 mm | 355 mm | 347 mm | 355 mm | 347 mm |
| Front Center | 776 mm | mm | 797 mm | mm | 822 mm | mm | 847 mm | mm |
| Rake | 44 mm | mm | 44 mm | mm | 43 mm | mm | 43 mm | mm |
| Trail | 128 mm | 133 mm | 128 mm | 133 mm | 128 mm | 133 mm | 128 mm | 133 mm |
| Stack | 626 mm | 631 mm | 635 mm | 640 mm | 647 mm | 652 mm | 658 mm | 663 mm |
| Reach | 438 mm | 431 mm | 455 mm | 438 mm | 475 mm | 468 mm | 495 mm | 488 mm |
| Top Tube Length | 590 mm | 593 mm | 609 mm | 612 mm | 632 mm | 635 mm | 654 mm | 657 mm |
| Seat Tube Angle | 76.3 ° | 75.7 ° | 76.3 ° | 75.7 ° | 76.3 ° | 75.7 ° | 76.3 ° | 75.7 ° |
| Head Tube Angle | 64.6 ° | 63.9 ° | 64.6 ° | 63.9 ° | 64.6 ° | 63.9 ° | 64.6 ° | 63.9 ° |
| Chainstay Length | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm | 430 mm | 432 mm |
| Wheelbase | 1205 mm | mm | 1226 mm | mm | 1251 mm | mm | 1276 mm | mm |
| Bottom Bracket Drop | 18 mm | 27 mm | 18 mm | 27 mm | 18 mm | 27 mm | 18 mm | 27 mm |
| Standover Height | 718 mm | 712 mm | 727 mm | 721 mm | 735 mm | 729 mm | 746 mm | 740 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
About this model
Wreckoning LS SRAM X0 Eagle T-TYPE I9 HYDRA (Custom Order) belongs to the Evil Wreckoning model. There are 39 bikes that carry this model name. You can easily view all of the Evil Wreckoning bikes models from 2023, here.
Model range prices
Evil Wreckoning – LS SRAM GX MECHANICAL i9 HYDRA 2023 is the cheapest bike model and costs 6999$. Evil Wreckoning – LS SRAM X0 Eagle Transmission Loopholes 2023 is the most expensive one and costs 9599$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Wreckoning LS SRAM X0 Eagle T-TYPE I9 HYDRA (Custom Order) components
Fork
Evil Wreckoning LS SRAM X0 Eagle T-TYPE I9 HYDRA (Custom Order) 2023 bike is equipped with the RockShox ZEB Ultimate fork, and has 170mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Rockshox Super Deluxe Coil Ultimate, with a travel distance of 166mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Evil Wreckoning LS SRAM X0 Eagle T-TYPE I9 HYDRA (Custom Order) 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Evil Wreckoning LS SRAM X0 Eagle T-TYPE I9 HYDRA (Custom Order) is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
Evil Wreckoning LS SRAM X0 Eagle T-TYPE I9 HYDRA (Custom Order) comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
