Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Factor HANZ? Toray® & Nippon Graphite® Pan-Based Fiber
Suspension Fork
Factor Wide Stance Fork
Drivetrain
Rear Derailleur
SRAM Red
Crank
170mm
Bottom Bracket
CeramicSpeed PF4630 Aluminium cups / CeramicSpeed bearings with Wheels MFG 24mm BBRight Reducers/Adapters
Wheels
Rims
Black Inc SIXTY
Brakes
Brakes
Rim
Cockpit
Headset
CeramicSpeed SLT 1? bearings
Seat
Seatpost
Factor HANZO Carbon Zero (0mm setback). 27mm setback also available.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.285 mm | 1.274 mm | 1.291 mm | 1.286 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 581 mm | 596 mm | 618 mm | 647 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 64 mm | 60 mm | 60 mm | 60 mm |
| Stack | 501 mm | 516 mm | 541 mm | 566 mm |
| Reach | 390 mm | 405 mm | 419 mm | 440 mm |
| Top Tube Length | 501 mm | 519 mm | 537 mm | 560 mm |
| Head Tube Angle | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 975 mm | 991 mm | 1012 mm | 1041 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
HANZO – SRAM Red is part of the Factor Hanzo model. 6 bikes variations carry this model name so far. Take a sneak peek at all Factor Hanzo bikes models from 2023, by clicking here.
Model range prices
The most economical model, the Factor HANZO – SRAM Force 2023 has a starting price of 9299$. Factor HANZO – SRAM Red w/ Power Meter 2023 on the other hand is the most expensive at 11399$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Aero bikes
Our math shows that the average cost of a dependable Aero bike is 4211$. However, you could also get a good Aero bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 10999$. If we compare this with the average Aero bike cost we notice that the price is 161.2% higher.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on HANZO – SRAM Red are the 700c carbon type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Factor HANZO – SRAM Red has Rim brakes installed. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
HANZO – SRAM Red comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
